Engineer Quick Reference
Engineer Menu 1
1-1
Program Zones
Zone type
:
0= Not Used Shunt Key
1= Normal Alm Tamper
2= 24 Hour Perimeter
3= PA Silent Lock Set
4= PA Audible PSU Battery
5= Fire PSU Fuse
6= Technical PSU Power
7= Final Exit Masking
8= Exit Term Occupancy
9= Entry Security
Keyswitch
Attributes
(toggle to change to YES/NO):
1= Access 9= Chime Tone 2
2= Double Knock Chime Tone 3
3= Soak Test Inverted
4= Omittable Shuntable
5= Reset Beam Pair
6= Masking Monitored
7= Entry Non Latching
8= Chime Tone 1
p24
1-2 Zones Advanced
Zone resistance:
1= 4K7/2K2 3= 4K7/4K7
2= 1K0/1K0 4= 2K2/2K2
p33
1-3 Ward Options
p35
1-3-1: Equipment to Wards
p35
1-3-2: Attributes
01= Conf Reset 09= Re-arms
02= Unconf Reset 10= Secure Ward
03= Tamper Reset 11= Bell & Strobe
04= Remote Reset 12= Foyer Mode
05= Panel Tamper 13= Unset Fire
06= Panel Speaker 14= Multiply Ack
07= Bell Tamp
08= Payment Timer
p36
1
-
4 Outputs
Output type
:
1= Panel 4= Equipment
2= Digi H/Wired 5= O/M Modules
(Not M550/M600)
3= Digi On Board 6= Custom Outputs
Follows:
1= System 4= User
2= Ward 5= Group
3= Zone
p39
If following the system:
000= Bell (SAB) 054=Always Off
001= System Strobe 055=Battery Test On
002= Switch 12 Volts 056=Battery Fault
003= Detector.Reset 057=PSU - Battery
004= Walk Test 058=PSU - Fuse
005= Alarm 059=PSU - Power
006= Panic Alarm (PA) 060=General Fault
007= Fire Alarm 061=Mask Tamper
008= System Set 062=Mask Fault
009=System Full Set 063=Not used
010=System Open 064=Not used
011=Confirmed 065=Pending
012=Courtesy Light 066=ID Loop Shorted
013=Engineer On Site 067=Ext Line Fault
014=Active Omit 068=ATS Test
015=Zones Omitted 069=Always Off
016=24 Hour Omitted 070=Auxiliary Fuse
017=24 Hour Alarm 071=Bell Fuse
018=Zones Shunted 072=Network 1 Fuse
019=Technical 073=Network 2 Fuse
020=PSTN Line Fault 074-079=Always Off
021=Mains Power Off 080=Rem Batt Fault
022=Access Code 081=Rem Mains Off
023=Soak Test Fail 082=Rem Pwr Out Flt
024=First Knock 083=Sys Batt Fault
025=Digi Failed 084=Sys Mains Fault
026=Digi Successful 085-099=Always Off
027=Digi Active 100=Auto-Setting
028=2nd Entry Only 101=Auto-Set Timer 1
029=Entry Only 102=Auto-Set Timer 2
030=Exit Only 103=Auto-Set Timer 3
031=Exit / Entry 104-108=Always Off
032=Exit Fault 109=PC Output 1 On
033=Tamper Alarm 110=PC Output 2 On
034=Rem Service Call 111=PC Output 3 On
035=Code Accepted 112=PC Output 4 On
036=Service Required 113-118=Always Off
037=Reset Required 119=Custom O/P 1 On
038=Strobe On Set 120=Custom O/P 2 On
039=Duress Alarm 121=Custom O/P 3 On
040=System Part Set 122=Custom O/P 4 On
041=LockSet Unlocked 123=Custom O/P 5 On
042=Set Failed 124=Custom O/P 6 On
043=Shunt Code 125=Custom O/P 7 On
044=Random Output On 126=Custom O/P 8 On
045=Modem Lockout 127-128=Always Off
046=Bell Tamper 129=Time Switch 1 On
047=Panel Lid Tamper 130=Time Switch 2 On
048=Chime Mimic 131=Time Switch 3 On
049=Monitored O/P On 132-138=Always Off
050=Alarm Abort 139=Code Lock 1 On
051=Rem Call Enabled 140=Code Lock 2 On
052=Relearn Required 141=Code Lock 3 On
053=Always On 142-148=Always Off
If following a ward:
00= Bell-SAB 22= Monitor
01= Strobe 23= Alm Abort
