Engineering Manual Engineer Quick Reference
127
02= Switch 12 24= Entry
03= Det.Reset 25= Exit
04= Walk Test 26= Exit/Ent.
05= Alarm 27= Exit Flt
06= P.A Alarm 28= Sndr Ctl.
07= Fire Alm. 29= Perimeter
08= Set 30= Shunted
09= 2nd Entry 31= AlwaysOff
10= 24Hr Alm. 32= SetStrobe
11= Cnf Alarm 33= Access
12= Zone Omit 34= LS Open
13= Act.Omit 35= PSU Batt
14= 24Hr Omit 36= PSU Fuse
15=Set Fail 37= PSU Mains
16=Settling 38= Mask Tamp
17=Clear 39= Mask Flt
18=Tamper 40= Auto Set
19=Reset Req
20=Lock-Out
21=Chime On
If following a zone:
1= Mimic 4= Test Fail
2= Alarm 5= Omit
3= Tamper
1-5
Timers
p56
1-5-1: Ward Timers
1= Exit 3= Bell Delay
2= Entry Delay 4= Bell Duration
p56
1-5-2: System Timers
01= Confirmation 16= Defer Setting
02= Sys Bell Dly 17= Service Time
03= Sys Bell Dur 18= Select Menu
04= Anti Mask 19= Keys Til Tamp
05= Line Fault 20= No. of Rearms
06= AC Off Delay 21= Remote Resets
07= Soak Test 22= Double Knocks
08= Exit Settle 23= Tst Call Strt
09= 2nd Entry Dly 24= Test Call Int
10= Double Knock. 25= Reset Alg.
11= Abort Period 26= Payment Time
12= Abort Delay 27= Hi Security
13= Courtesy Time
14= Menu time-Out
15= Beam Pair
p58
1-5-3: Time Switches
p62
1-5-4: Auto-Sets
p63
1
-
5
-
5
: Code Locks
p64
1-6 Setting Modes
1= Final Exit 4= Instant Set
2= Exit Terminate 5= Deferred Set
3= Timed Exit 6= Lock Set
p65
1
-
7 Custom Text
1= Reset message 5= Banner Text
2= Location text 6= Group Names
3= Printer title 7= Aux. Tamper
4= Remote Reset Msg
p67
1-8 Group Options
p69
1-8-1: Assign Groups
Group 1 to 4 (max.)
p69
1
-
8
-
2
: Exit Modes
1= Final Exit 5= Deferred Set
2= Exit Terminate 6= Lock Set
3= Timed Exit 7= Silent Set
4= Instant Set
p70
1-8-3: Group Timers
1= Exit 3= Bell Delay
2= Entry Delay 4= Bell Duration
p71
1-8-4: Alarm Response
1= Full 3= Internal
2= Local
p72
1-9 Configuration
p73
1-9-1: General
01 = Ward OFF / ON
02 = Bell is an SAB / Bell is an SCB
03 = View Alms Unset / View Alms P.set
04 = Engr Authorised / User Authorised
05 = On-Line Enabled / Disabled
06 = Unset Ward First / Set Ward First
07 = Digi Normal / Digi Inverted
08 = Chime Audible /Chime Visible
09 = Manual Omits / Automatic Omits
10 = Omit Tampers No / Omit Tampers Yes
11 = Global Setting / Local Setting
12 = Global Unsetting / Local Unsetting
13 = 24hr Omit Global / 24hr Omit Local
14 = Ward Bell Time / Global Bell Time
15 = Latching Fire / Nonlatching Fire
16 = Timed code o/p / Latched code o/p
17 = Latching 24hr / Nonlatching 24hr
18 = Access code only / Access all codes
19 = NVM is Unlocked / NVM is Locked
20 = Unshunt, no exit / Unshunt & exit
21 = Ignore errors / View exit errors
22 = Mimic, All times / Mimic, Set only
23= Lo Security Eng. / Hi Security Eng.
24= Duress Allow NO / YES
25= Keypad PA OFF/ON
26= P.Set Hotkey YES/NO
27 = Exit Foyer / Inst Set Foyer
p73
1
-
9
-
2
: DD243
01 = Confirmation On / Off
02= Sndrs on Unconf / Confirm
03= Bells on Unconf / Confirm
04= After Entry No / Yes
05= Ent KPD Lock Off / On
06= Confirm 2 Zones / Confirm 1 Zone
p77
1-9-3: EN50131
01= 4 Digit Codes / 6 Digit Codes
02= Internal Sounder / Local Sounder
03= Int Sounder Inst / Dly
04= Instant Alarm / Delayed Alarm
05= Tampers As Alarm / Tampers As Tamps
06= Mask Unset Fault / Mask Unset Tamp
07= Mask Set Fault / Mask Set Tamper
08= Mask Override / Mask Inhibit
09= Gen/fault: User / Eng
10= AC Fail: No Reset / User / Engineer
11= AC Bypass: Always / Healthy / Never
12= Line Fail: No Rst / User / Eng
13= LF Bypass: Always / User / Eng
p79
1-0 Goto User Menu 1
p81
