Engineer Menu 1-3 Engineering Manual
36
you can make keypad sounders produce only those sounds that are relevant to a
specific ward.
By default, the sounder in keypads connected directly to a network follow the wards
assigned to the extension loudspeaker. For example, if the extension loudspeaker is
assigned to wards 1 and 2, the keypad sounders operate when ward 1 or 2 requires an
entry, exit or alarm sounder. However, using the Sndr Ctl output type (page 53), you can
make keypad sounders produce only those sounds that are relevant to a specific ward.
Option 1-3-2: Defining Ward Attributes
Ward Options 2
Attributes
Conf Reset 01
Ward :........
e.g.
Shows wards that
attribute applies to
Note:
Equip to Wards
See previous section for
option
[
Eng 1 Menu 3
Ward Options
Unconf Reset 02
Ward :........
Unconf Reset 02
Ward > ****....
Unconf Reset 02
Ward > 1***....
Ward Options 1
Equip To Wards
[
[
[
|
|
e.g.
To select attribute:
Press or
"
"
|¬
to scroll, or
Press attribute hot key (e.g. 04)
Press ward number
18
to to toggle
device in ward (ward number shown) or not
in ward ("*" displayed).
Press to save changes and continue
[
1. SELECT "ATTRIBUTES" OPTION
2. SELECT ATTRIBUTE TYPE
3. SELECT WARDS ATTRIBUTE
APPLIES TO
The Attributes option allows you to assign attributes to wards to affect system behaviour. The
following attributes are available:
01 – Conf Reset
If you select this attribute, an engineer or remote reset code must be entered to reset the
system after a confirmed alarm (page 77) has been sounding in the selected wards for
at least the period specified by Abort Delay (page 59). If you deselect this option, any
user who has access to the ward can reset the confirmed alarm. See also the Remote
Reset attribute (page 37).
02 – Unconf Reset
If you select this attribute, an engineer or remote reset code must be entered to reset the
system after an unconfirmed alarm (page 77) has been sounding in the selected wards
To Next Page
