Engineering Manual Compliance Guide
125
PD 6662 / prEN 50131-1: 2004 Compliance
EN 50131-1: 2004, Alarm systems – Intrusions and Hold-up Systems – Part 1: System
Requirements, sets four grades for intruder alarm systems to provide levels of security required
for specific risks. M750, M800, M800iD Plus, and M1000 control panels can be configured to
fulfil the requirements of Grades 1 to 3. M550 and M600 panels can be configured to fulfil
Grade 1 or 2. Note: This guide does not apply to EN 50131-1:1997.
Configuring Hardware
Zones can be wired as either double-pole or FSL (fully-supervised loop), as described in the
Installation Instructions, but FSL is recommended. To allow remote servicing, FSL should be
used.
The power available for connecting external devices to the control unit depends on the
battery used and the grade to which the system is configured. Please refer to "Power
Availability" in the Installation Instructions.
The built-in modem (not available on M550 or M750) is suitable for signalling alarms at Grades
1 and 2. If it is used, test calls must be made (set with E1-5-2-23/24 as described below). At
Grade 3, an external communicator is needed to provide the necessary encryption.
Programming for Compliance
E1-9-3 provides most of the options needed to fulfil the requirements of PD 6662 / prEN 50131-
1: 2004, but you need to use some others as well. Use the settings shown in the following table.
Option Name Grade 1/2 Grade 3 Notes
E1-5-1-2 Ward Entry Delay Timer ≤ 45 secs ≤ 45 secs
E1-5-1-3 Ward Bell Delay
≤ 10 min ≤ 10 min
E1-5-1-4 Ward Bell Duration
≤ 15 min ≤ 15 min
E1-5-2-02 System Bell Delay
≤ 10 min ≤ 10 min
E1-5-2-03 System Bell Duration
≤ 15 min ≤ 15 min
E1-5-2-23 /
E1-5-2-24
Test Call Strt/
Test Call Int
≤ 25 hours N/A
Use an external communicator for Grade
3; test calls no more than 5 hours apart.
See "Configuring Hardware" above
E1-9-3-01 4 / 6 Digit Codes
Any 6 digit
Applies even when using proximity tags
because the installer and user 01 still use
passcodes
E1-9-3-02 Internal / Local Sounder
Any Any
During Entry Delay Timer
E1-9-3-04 Instant / Delayed Alarm
Delayed Delayed
E1-9-3-05 Tampers as Alarms /
Tampers
Tampers Tampers
Sending tampers as tampers is
recommended at Grades 1 and 2 and
mandatory at Grade 3
E1-9-3-06 Mask Unset as Fault /
Tamper
Fault Fault
E1-9-3-07 Mask Set as Fault / Tamper
Fault Fault
E1-9-3-08 Mask Override / Inhibit
Any Any
Insurers may require a restriction
E1-9-3-09 General Fault Reset
Any Any
Insurers may require a restriction
E1-9-3-10 AC Fail Reset
User/Engineer User/Engineer
User is recommended
E1-9-3-11 AC Bypass
Any Any
Insurers may require a restriction
E1-9-3-12 Line Fail Reset
User/Engineer User/Engineer
User is recommended
E1-9-3-13 Line Fail Bypass
Any Any
Insurers may require a restriction
E2-5-3-4 Access Mode
Not Unattended Not Unattended
