Engineer Menu 2-7 Engineering Manual
112
Option Settings Defaulted Default Value
01 Confirmation On
02 Sndrs on Unconf
03 Bells on Unconf
04 After Entry No
05 Ent KPD Lock Off
DD243
(Eng 1-9-2)
06 Confirm 2 Zones
01 4 Digit Codes
02 Internal Sounder
03 Int Sounder Inst
04 Instant Alarm
05 Tampers As Alarm
06 Mask Unset Fault
07 Mask Set Fault
08 Mask Override
09 Gen/fault: User
10 AC Fail: No Reset
11 AC Bypass: Always
12 Line Fail: No Reset
... Continued:
Configuration
EN50131
(Eng 1-9-3)
13 LF Bypass: Always
Panel Output 1 Walk Test
Panel Output 2 Courtesy Light
Panel Output 3 System Strobe
Panel Output 4 Detector Reset
Panel Output 5 General Fault
Digi H/Wired 01 Fire Alarm
Digi H/Wired 02 Panic Alarm (PA)
Digi H/Wired 03 Alarm
Digi H/Wired 04 System Set
Digi H/Wired 05 Active Omit
Digi H/Wired 06 General Fault
Digi H/Wired 07 Confirmed
Digi H/Wired 08 Tamper Alarm
Digi H/Wired 09 Mains Power Off
Digi H/Wired 10 Zones Omitted
Digi H/Wired 11 PSTN Line Fault
Digi H/Wired 12 Technical
Digi H/Wired 13 ATS Test
Digi H/Wired 14 Always Off
Digi H/Wired 15 Always Off
Digi H/Wired 16 Always Off
Digi On Board 01 Fire Alarm
Digi On Board 02 Panic Alarm (PA)
Digi On Board 03 Alarm
Digi On Board 04 System Set
Digi On Board 05 Active Omit
Digi On Board 06 General Fault
Digi On Board 07 Confirmed
Digi On Board 08 Tamper Alarm
Digi On Board 09 Mains Power Off
Digi On Board 10 Zones Omitted
Digi On Board 11 PSTN Line Fault
Digi On Board 12 Technical
Digi On Board 13 Always Off
Digi On Board 14 Always Off
Digi On Board 15 Always Off
Digi On Board 16 Always Off
All Equipment outputs Pending
All Output Module outputs Always Off
Outputs
(Eng 1-4)
Custom outputs See page 41
To Next Page
