OUTPUT TYPE
System Ward Zone Tamper
Triggered
(Example)
Panel
Status
"Tampers
As"
Alarm Tamper Alarm Tamper Alarm Tamper
Panel Unset Alarms Off On Off On Off Off
Keypad Unset Alarms Off On Off On Off Off
Zone Unset Alarms Off On Off On Off On
Panel Set Alarms On On On On Off Off
Keypad Set Alarms On On On On Off Off
Zone Set Alarms On On On On On On
Panel Unset Tampers Off On Off On Off Off
Keypad Unset Tampers Off On Off On Off Off
Zone Unset Tampers Off On Off On Off On
Panel Set Tampers Off On Off On Off Off
Keypad Set Tampers Off On Off On Off Off
Zone Set Tampers Off On Off On Off On
Effect of Tampers as Alarms on Output Operation
06 – Mask Unset Fault / Mask Unset Tamp
Mask Unset Fault (default) – The system will consider a masking condition (page 29)
when the zone is unset as a fault condition. Outputs programmed as Mask Fault (system
output; page 48) or Mask Flt (ward output; page 54) will activate.
Mask Unset Tamp – The system will consider a masking condition when the zone is unset
as a tamper condition. Outputs programmed as Mask Tamper (system output; page 48
or Mask Tamp (ward output; page 54) will activate.
07 – Mask Set Fault / Mask Set Tamper
Mask Set Fault (default) – The system will consider a masking condition (page 29) when
the zone is set as a fault condition. Outputs programmed as Mask Fault (system output;
page 48) or Mask Flt (ward output; page 54) will activate.
Mask Set Tamper
– The system will consider a masking condition when the zone is set as
a tamper condition. Outputs programmed as Mask Tamper (system output; page 48 or
Mask Tamp (ward output; page 54) will activate.
08 – Mask Override / Mask Inhibit
Mask Override
(default)
– Allows a user to set a ward that has a masking condition (page
29).
Mask Inhibit – Prevents a user from setting a ward that has a masking condition (page
29).
09 – Gen/fault: User / Eng
User
(default)
– With this option selected, a user can override a general fault (page 47)
when setting the alarm system.
Eng – Prevents the alarm system from being set if there is a general fault (page 47).
10 – AC Fail:No Reset / User / Engineer
No Reset (default) – An AC Mains Fault alert will exist while the mains supply is switched
off, but will automatically disappear when the mains is restored. No resetting of the alert
is required.
The AC Off Delay timer (page 59) determines how long the mains must be off
before the system generates an alert.
User
– An alert generated by a mains failure will require a normal user reset.
