FC 300 Design Guide
How to Program
Logic rule 2 [28]
Logic rule 3 [29]
Digital input DI18 [33]
Digital input DI19 [34]
Digital input DI27 [35]
Digital input DI29 (FC 302 only) [36]
Digital input DI32 [37]
Digital input DI33 [38]
Start command [39]
Stop command [40]
Function:
Select the b oolean (TRUE or FALSE) input to
activate Sm art L ogic Control.
*False [0] (default setting) enters the fixed
value of FALSE in the logic rule.
True [1] enters the fixed value TRUE in the logic rule.
Running [2] See parameter group 5-3*
for further description.
In rang e [3] See parameter group 5-3*
for further description.
On reference [4] See parameter group 5-3*
for further description.
Torque lim it [5] See parameter group 5-3*
for further description.
Current limit [6] See parameter group 5-3*
for further description.
Out of current ra nge [7 ] See parameter group
5-3* for further description.
Below I low [8] See parameter g roup 5-3*
for further description.
Above I high [9 ] See parameter group 5- 3*
for further description.
Below frequency low [11] See parameter group
5-3* for further description.
Above frequ ency high [1 2] See parameter group
5-3* for further description.
Thermal warning [16] See parameter group
5-3* for further description.
Mains voltage out of range [17] See parameter
group 5-3* for further description.
Reversing [18] See parameter group 5-3*
for further description.
Warning [19 ] See parameter group 5-3*
for further description.
Alarm (trip) [20 ] See p arameter group 5-3*
for further description.
Alarm (trip lock) [21] See p arameter group
5-3* for further description.
Comparator 0 [22] Use the result of comparator
0 in the logic rule.
Comparator 1 [23] Use the result of comparator
1 in the logic rule.
Comparator 2 [24] Use the result of comparator
2 in the logic rule.
Comparator 3 [25] Use the result of comparator
3 in the logic rule.
Logic rule 0 [26] Use the result of logic
rule 0 i n the logic rule.
Logic rule 1 [27] Use the result of logic
rule 1 i n the logic rule.
Logic rule 2 [28] Use the result of logic
rule 2 i n the logic rule.
Logic rule 3 [29] Use the result of logic
rule 3 i n the logic rule.
Digital input DI18 [33]UsethevalueofDI18
in the logic rule (High = TRUE).
Digital input DI19 [34]UsethevalueofDI19
in the logic rule (High = TRUE).
Digital input DI27 [35]UsethevalueofDI27
in the logic rule (High = TRUE).
Digital input DI29 [36]UsethevalueofDI29
in the logic rule (High = TRUE).
Digital input DI32 [37]UsethevalueofDI32
in the logic rule (High = TRUE).
Digital input DI33 [38]UsethevalueofDI33
in the logic rule (High = TRUE).
13-02 Stop Event
Option:
FALSE [0]
TRUE [1]
Running [2]
In range [3]
On reference [4]
Tor q ue l imi t [5]
Current limit [6]
Out of current range [7]
Below I low [8]
Above I high [9]
Below speed low [11]
Above speed high [12]
Out of feedb. range [13]
Below feedb. low [14]
Above feedb. high [15]
Thermal warning [16]
Mains out of range [17]
*
default setting ()display text []value for use in communication via serial communication port
