How to Program
" Parameters: Data Read-outs
" 16-** Data Read-outs
Parametergroupfordataread-outs,e.g.,
current references, voltages, control, alarm,
warning and status words.
" 16-0* General Status
Parameters for reading the general status, e.g., the
calculated reference, the act ive control word, status.
16-00 Control W ord
Range:
0 - FFFF
*
0
Function:
View the control word sent from the adjustable
frequency d rive via the serial communication
port in hex code.
16-01 Refe rence [Unit]
Range:
-999999.000 - 999999.000
*
0.000
Function:
View the present reference value applied on impulse
or analog basis in the unit resulting from the
configuration selected in par. 1-00 (Hz, Nm or RPM).
16-02 Reference %
Range:
-200.0 - 200.0%
*
0.0%
Function:
View the total reference. The total reference is
the sum of digital, analog, preset, bus, and freeze
references, plus catch-up and slow-down.
16-03 Status Wor d
Range:
0 - FFFF
*
0
Function:
View the status word sent from the adjustable
frequency d rive via the serial communication
port in hex code.
16-05 Main actual value [%]
Option:
0-0N/A
*
N/A
Function:
Two-byte word sent with the Status word to the
Bus Master rep orting the main actual value.
Please refer to the VLT
®
AutomationDrive FC
300 Profibus Instruction Manual MG.33.CX.YY
for detailed description.
" 16-1* Motor Status
Parameters for reading the motor status values.
16-10 Power [kW]
Range:
0.0 - 1000.0 kW
*
0.0kW
Function:
View the motor power in kW. The value shown
is calculated on the basis of the actual motor
voltage and motor current. The value is filtered,
and there fore approx. 1.3 seconds may pass
from when an input value changes to when
the data read-out values change.
16-11 Power [hp]
Range:
0.00 - 1000.00 hp
*
0.00hp
Function:
View the motor power in hp. The value shown
is calculated on the basis of the actual motor
voltage and motor current. The value is filtered,
and there fore approx. 1.3 seconds may pass
from when an input value changes to when
the data read-out values change.
16-12 Motor voltage
Range:
0.0 - 60 00.0 V
*
0.0V
Function:
View the motor voltage, a calculated value
used for controlling the motor.
16-13 Frequency
Range:
0.0 - 6500 .0 Hz
*
0.0Hz
Function:
View the motor frequency, without reso-
nance dampening.
*
default setting ()display text []value for use in communication via serial communication port
245
MG.33.B
6.22 - V LT is a registered Danfoss trademark
