How to Order
" Ordering Numbers
" Ordering Numbers: Options and Accessories
Type Descriptio n Ordering no.
Miscellaneous hardware
DC link connector Terminal block for DC link connection on frame size A2/A3 130B1064
IP 21/4X top/TYPE 1 kit Enclosure, frame size A2: IP 21/IP 4X Top/TYPE 1 130B1122
IP 21/4X top/TYPE 1 kit Enclosure, frame size A3: IP 21/IP 4X Top/TYPE 1 130B1123
Profibus D-Sub 9 Connector kit for IP 20 130B1112
Profibus top entry kit Top entry kit for Profibus connection 130B0524
1)
Terminal blocks Screw terminal blocks for replacing spring loaded terminals
1 x 10-pin, 1 x 6-pin and 1 x 3-pin connectors 130B1116
LCP
LCP 101 Numerical Local Control Panel (NLCP) 130B1124
LCP 102 Graphical Local Control Panel (GLCP) 130B1107
LCP cable Separate LCP cable, 9.8 ft. [3 m] 175Z0929
LCP kit Panel mounting kit including graphical LCP, fasteners, 9.8
ft. [3 m] cable and gasket
130B1113
LCP kit Panel m ou nting kit including numerical LCP, fasteners and
gasket
130B1114
LCP kit Panel mounting kit for all LCPs including fasteners, 9.8
ft. [3 m] cable and gasket
130B1117
Options for Slot A Uncoated / Coated Uncoated Coated
MCA 101 Profibus option DP V 0/V1 130B1100 130B1200
MCA 104 DeviceNet option 130B1102 130B1202
MCA 105 CANopen 130B1103
Options for Slot B
MCB 101 General purpose Input Output option 130B1125
MCB 102 Encoder option 130B1115
MCB 103 Resolver option 130B1127 130B1227
MCB 105 Relay option 130B1110
MCB 108 Safety PLC interface (DC/DC drive) 130B1120
Option for Slot D
MCB 107 24 V DC back-up 130B1108 130B1208
External Options
Ethernet IP Ethernet master 175N2584
Spare Parts
Control board FC 302 Coated version 130B1109
Control board FC 301 Coated version 130B1126
Fan A2 Fan, frame size A2 130B1009
Fan A3 Fan, frame size A3 130B1010
Accessory bag B Accessory bag, frame size A2 130B0509
Accessory bag C Accessory bag, frame size A 3 130B0510
1) Only IP 21 / > 14.75 HP [11 kW]
Options can be ordered as factory built-in opt ions, see ordering information.
For infor mation on serial communication bus and application option com patibility with older
software versions, please contact your Danfoss supplier.
87
MG.33.B6.22 - VLT is a registered Danfoss trademark
