FC 300 Design Guide
FC 300 Selection
" General Specifications
Protection and Features:
Electronic thermal motor protection against overload.
Temperature monitoring of the heatsink ensures that the adjustable frequency drive trips if the
temperature reaches 203°F ± 9°F [95 °C ± 5°C]. An overload temperature cannot be reset
until the te m perature of the he a tsink is below 158°C ± 9°C [70°C ± 5°C] (Guide line - these
temperatures may vary for diffe r ent power sizes, enclosures, e tc.).
The adjustable fre quency drive is protecte d against short circuits on motor terminals U, V, W.
If a line phase is missing, the adjustable frequency drive trips or issues a warning (depending on the load).
Monitoring of the interm ediate circuit voltage ensures that the adjustable frequency drive
trips if the intermediate circuit voltage is too low or too high.
The adjustable frequency drive is protected against g round faults on motor terminals U, V, W.
Mains supply (L1, L2, L3):
Supply voltage ....................................................................................................... 200-240 V ±10%
Supply voltage ............................................................. FC 301: 380-480 V / FC 302: 380-500 V ±10%
Supply voltage ........................................................................................... FC 3 02: 525-600 V ±10%
Supply frequency ............................................................................................................... 50/60 Hz
Max. imbalance temporary between mains phases ..................................... 3.0 % of rated supply voltage
TruePowerFactor(λ) .................................................................................. 0.90 nominal at rated load
Displacement Power Factor (cos ϕ) near unity ........................................................................ (> 0.98)
Switching on input supply L1, L2, L3 ................................................................................ 2 times/min.
Environment according to EN60664-1 .................................... overvoltage category III/pollution degree 2
The unit is suitable for use on a circuit capable of delivering not more than 100,000
RMS symmetrical Amperes, 240/500/600 V maximum.
Motor output (U, V, W):
Output voltage .......................................................................................... 0 - 100% of supply voltage
Output frequency ............................................................. FC 301: 0.2 - 1000 Hz / FC 302: 0 - 1000 Hz
Switching on output ........................................................................................................... Unlimited
Ramp times ............................................................................................................. 0.01 - 3600 sec.
Torque characteristics:
Starting torque (Constant torque) ............................................................................ 160% for 1 min.
*
Starting torque ................................................................................................ 180% up to 0.5 sec.
*
Overload torque (Constant torque) ........................................................................... 160% for 1 min.
*
*Percentage relates to FC 300’s nominal torque.
Cable lengths and cross -sections:
Max. motor cable length, shielded/armored ..................... FC 301: 150 ft (50 m) / FC 302: 500 ft (15
0m)
Max. motor cable length, non-shielded/unarmored ......... FC 301: 250 ft (75 m) / FC 302: 1000 f t (300 m)
Max. cross-section to motor, mains, load sharing and brake (see section Electrical Data in the
FC 300 De sign Guide MG.33.BX.YY for more information), (0.34 HP - 10 HP / 0.25 kW - 7
.5
kW) ...................................................................................................... 0.006 in.
2
(4 mm
2
)/10AWG
Maximum cross-section to control wires, rigid wire ................................................................................
0.002 in.
2
(1.5 mm
2
)/16 AWG (2 x 0.001 in.
2
(2 x 0.75 mm
2
))
Maximum cro ss-se ction to control c ables, flexible cable .............................. 0.0015 in.
2
(1 mm
2
)/18 AWG
Maximum cro ss-se ction to control cables, cable with enclosed core ............ 0.0008 in.
2
(0.5 mm
2
)/20 AWG
60
MG.33.B6.22 - VLT is a registered Danfoss trademark
