FC 300 Design Guide
How to Program
" Parameters: Digital In/Out
" 5-** Digital In/Out
Parametergroupforconfiguringthedigital
input and output.
" 5-0* Digital I/O Mode
Parameters for configuring the IO mode. NPN/PNP
and setting up IO to input or output.
5-00 Digital I/O Mode
Option:
*
PNP [0]
NPN [1]
Function:
Digital inputs and programmed digital outputs
are p re-programmable for operation either
in PNP or NPN systems.
Select PNP [0] systems for action on positive
directional pulses (). PNP systems are
pulled down to GND.
Select NPN [1]systemsforactiononnegative
directional pulses (). NPN systems are pulled up to
+ 24 V, internally in the frequency converter.
This parameter cannot be adjusted while
the motor is running.
5-01 Termin al 27 Mode
Option:
*
Input [0]
Output [1]
Function:
Select Input [0] to define term inal 27
as a digital input.
Select Output [1] to define terminal 27
as a digital output.
This parameter cannot be adjusted while
the motor is running.
5-02 Termin al 29 Mode
Option:
*
Input [0]
Output [1]
Function:
Select Input [0] to define term inal 29
as a digital input.
Select Output [1] to define terminal 29
as a digital output.
This parameter is available for the FC 302 only.
This parameter cannot be adjusted while
the motor is running.
" 5-1* Digital Inputs
Parameters for configuring the input functions
for the input terminals.
The digital inputs are used for selecting various
functions in the frequency converter. All digital
inputs can be set to the following functions:
Digital input function Select Terminal
No operation [0] All *term 32, 33
Reset [1] All
Coast i nverse [2] All *term 27
Coastandresetinverse [3] All
Quick stop inverse [4] All
DC-brake inverse [5] All
Stop inverse [6] All
Start [8] All *term 8
Latched start [9] All
Reversing [10] All *term 19
Start reversing [11] All
Enable start forward [12] All
Enable start reverse [13] All
Jog [14] All *term 29
Preset reference on [15] All
Preset ref bit 0 [16] All
Preset ref bit 1 [17] All
Preset ref bit 2 [18] All
Freeze reference [19] All
Freeze output [20] All
Speed up [21] All
Speed down [22] All
Set-up select bit 0 [23] All
Set-up select bit 1 [24] All
Precise stop inverse [26] 18, 19
Precises start, stop [27] 18, 19
Catch up [28] A ll
Slow down [29] All
Counter input [30] 29, 33
Pulse input [32] 29, 33
Ramp bit 0 [34] All
Ramp bit 1 [35] All
Mains failure inverse [36] All
Latched precise start [40] 18, 19
Latched precise stop
inverse
[41] 18, 19
DigiPot Increase [55] All
DigiPot Decrease [56] All
DigiPot Clear [57] All
Counter A (up) [60] 29, 33
Counter A (down) [61] 29, 33
Reset Counter A [62] All
Counter B (up) [63] 29, 33
Counter B (down) [64] 29, 33
Reset Counter B [65] A ll
*
default setting ()display text []value for use in communication via serial communication port
