FC 300 Design Guide
How to Install
" Basic Wiring Example
1. Mount terminals from the accessory bag
to the front of the FC 300.
2. Connect terminals 18, 27 and 37 (FC 302
only) to +24 V (terminal 12/13)
Default settings:
18 = start
27 = coast inverse
37 = safe stop inverse
107
