" Control Word according to PROFIdrive
Profile ( CTW)
The control word is used to send commands
from a master ( e.g., a PC) to a slave.
Master => slave
1 2 3 ..... 10
CTW MRV PCD ..... PCD
PCD read/write
Explanation of the Control Bits
Bit Bit value = 0 Bit value = 1
00 OFF 1 ON 1
01 OFF 2 ON 2
02 OFF 3 ON 3
03 Coasting No coasting
04 Quick stop Ramp
05 Hold frequency output. Use ramp
06 Ramp stop Start
07 No func tion Reset
08 Jog 1 OFF Jog 1 ON
09 Jog 2 OFF Jog 2 ON
10 Data invalid Data valid
11 No function Slow-down
12 No function Catch up
13 Parameter set-up 1 Selection lsb
14 Parameter set-up 2 Selection msb
15 No func tion Reverse
Bit 00, OFF 1/ON 1:
Normal ramp stop uses the ramp tim es of the currently selected ramp. B it 00 = "0": Stops and activates
the output relay 1 or 2, if the output frequency is 0 Hz and if Relay 123 is sel ected in par. 5-40. Bit
00 = "1": The adjustable frequency drive starts if the other s
tart conditions are met.
B
it 01, OFF 2/ON 2
Bit 01 = "0": Coasting stop and activation of the output relay 1 or 2 occurs if the output
frequency is 0 Hz and if relay 123 is selected in par. 5-4 0. Bit 01 = "1": The adjustable
frequency drive starts if the other start conditions are me
t.
B
it 02, OFF 3/ON 3
A quick stop uses the ramp time of par. 2-12. Bit 02 = "0": A quick stop and activation of the output
relay 1 or 2 occurs if the output frequency is 0 Hz and if relay 123 is selected in par. 5-40. Bit 02 =
"1": Theadjustablefrequencydrivestartsiftheot
her start conditions are met.
B
it 03, Coast i ng/No coasting
Bit 03 = "0": Leads to a stop. Bit 03 = "1": The adjustable frequency drive starts
if the other start conditions are met.
*
