Danfoss FC 300 Design Guide

FC 300 Design Guide
FC 300 Selection
" Electrical Data
" Line Supply 3 x 200 - 240 VAC
FC 301/FC 302
Typical Shaft Output [kW]
0.25 0.37 0.55 0.75 1.1 1.5 2.2 3 3.7 4 5.5 7.5
Output current
Continuous
(3 x 200-240 V) [A]
1.8 2.4 3.5 4.6 6.6 7.5 10.6 12.5 16.7 - - -
Intermittent
(3 x 200-240 V) [A]
2.9 3.8 5.6 7.4 10.6 12.0 17.0 20.0 26.7 - - -
Continuous
KVA (208 V AC) [KVA]
0.65 0.86 1.26 1.66 2.38 2.70 3.82 4.50 6.00 - - -
Max. cable s ize
(line, motor, brake)
[AWG]
2)
[mm
2
]
24 - 10 AWG
0.0079-0.1575 in [0.2-4 mm]
2
---
Max. input current
Continuous
(3 x 200-240 V) [A]
1.62.23.24.15.96.89.511.315.0- - -
Intermittent
(3 x 200-240 V) [A]
2.6 3.5 5.1 6.6 9.4 10.9 15.2 18.1 24.0 - - -
Max. pre-fuses
1)
[A] 101010102020203232---
Environment
Estimated power loss
at rated max. load [W]
4)
21 29 42 54 63 82 116 155 185 - - -
Enclosure IP 20
Weight, enclosure IP 20
[kg]
4.74.74.84.84.94.94.96.66.6- - -
Efficiency
4)
0.94 0.94 0.95 0.95 0.96 0.96 0.96 0.96 0.96 - - -
55
MG.33.B6.22 - VLT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
