Danfoss FC 300 Design Guide

FC 300 Design Guide
FC 300 Selection
" Line Supply 3 x 380 - 500 VAC (FC 302)
3x380-480VAC(FC301)
FC 301/FC 302
Typical Shaft Output [kW]
0,25 0.37 0.55 0.75 1.1 1.5 2.2 3 3.7 4 5.5 7.5
Output current
Continuous
(3 x 380-440 V) [A]
- 1.3 1.8 2.4 3 4.1 5.6 7.2 - 10 13 16
Intermittent
(3 x 380-440 V) [A]
- 2.1 2.9 3.8 4.8 6.6 9.0 11.5 - 16 20.8 25.6
Continuous
(3 x 440-500 V) [A]
- 1.2 1.6 2.1 2.7 3.4 4.8 6.3 - 8.2 11 14.5
Intermittent
(3 x 440-500 V) [A]
- 1.9 2.6 3.4 4.3 5.4 7.7 10.1 - 13.1 17.6 23.2
Continuous KVA
(400 V AC) [KVA]
- 0.9 1.3 1.7 2.1 2.8 3.9 5.0 - 6.9 9.0 11.0
Continuous KVA
(460 V AC) [KVA]
- 0.9 1.3 1.7 2.4 2.7 3.8 5.0 - 6.5 8.8 11.6
Max. cable size
(line, motor, brake)
[AWG]
2)
[mm
2
]
-
24 - 10 AWG
0.0079-0.1575 in [0.2-4 mm]
2
-
24 - 10 AWG
0.0079-0.1575 in
[0.2-4 mm]
2
Max. input current
Continuous
(3 x 380-440 V) [A]
- 1.2 1.6 2.2 2.7 3.7 5.0 6.5 - 9.0 11.7 14.4
Intermittent
(3 x 380-440 V) [A]
- 1.9 2.6 3.5 4.3 5.9 8.0 10.4 - 14.4 18.7 23.0
Continuous
(3 x 440-500 V) [A]
- 1.0 1.4 1.9 2.7 3.1 4.3 5.7 - 7.4 9.9 13.0
Intermittent
(3 x 440-500 V) [A]
- 1.6 2.2 3.0 4.3 5.0 6.9 9.1 - 11.8 15.8 20.8
Max. pre-fuses
1)
[A] - 10 10 10 10 10 20 20 - 20 32 32
Environment
Estimated power loss
at rated max. load [W]
4)
- 35 42 46 58 62 88 116 - 124 187 255
Enclosure IP 20
Weight,
enclosure IP 20 [kg]
- 4.7 4.7 4.8 4.8 4.9 4.9 4.9 - 4.9 6.6 6.6
Efficiency
4)
- 0.93 0.95 0.96 0.96 0.97 0.97 0.97 - 0.97 0.97 0.97
56
MG.33.B6.22 - VLT is a registered Danfoss trademark
