Danfoss FC 300 Design Guide

FC 300 Design Guide
FC 300 Selection
Line Supply 3 x 380 - 500 VAC
High Overload 160% for 1 minute
FC 302
Typical Shaft Output [kW]
11 15 18.5 22
Output current
Continuous
(3 x 380-440 V) [A]
24 32 37.5 44
Intermittent
(3 x 380-440 V) [A]
38.4 51.2 60 70.4
Continuous
(3 x 440-500 V) [A]
21 27 34 40
Intermittent
(3 x 440-500 V) [A]
33.6 43.2 54.4 64
Continuous KVA
(400 V AC) [KVA]
16.6 22.2 26 30.5
Max. input current
Continuous
(3 x 380-440 V) [A]
22 30 35 42
Intermittent
(3 x 380-440 V) [A]
35.2 48 56 67.2
Continuous
(3 x 440-500 V) [A]
20 25 32 38
Intermittent
(3 x 440-500 V) [A]
32 40 51.2 60.8
Max. cablesize[mm
2
/AWG]
2)
16/6 16/6 35/2 35/2
Max. pre-fuses [A]
1
63 63 63 80
Estimated power loss
at rated max. load [W]
4)
272 382 454 513
Enclosure IP 21, IP 55
Weight,
enclosure IP 21, IP 55 [kg]
23 23 28 28
Efficiency
4)
0.98 0.98 0.98 0.98
57
MG.33.B6.22 - VLT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
