Danfoss FC 300

FC 300 Design Guide
FC 300 Selection
Line Supply 3 x 380 - 500 V AC
Normal Overload 110% for 1 minute
FC 302
Typical Shaft Output [kW]
15 18.5 22 30
Output current
Continuous
(3 x 380-440 V) [A]
32 37.5 44 61
Intermittent
(3 x 380-440 V) [A]
35.2 41.3 48.4 67.1
Continuous
(3 x 440-500 V) [A]
27 34 40 52
Intermittent
(3 x 440-500 V) [A]
29.7 37.4 44 57.2
Continuous kVA
(400 V AC) [kVA]
22.2 26 30.5 42.3
Continuous kVA
(460 V AC) [kVA]
21.5 27.1 31.9 41.4
Max. input current
Continuous
(3 x 380-440 V) [A]
30 35 42 58
Intermittent
(3 x 380-440 V) [A]
33 38.5 46.2 63.8
Continuous
(3 x 440-500 V) [A]
25 32 38 49
Intermittent
(3 x 440-500 V) [A]
27.5 35.2 41.8 53.9
Max. cablesize[mm
2
/AWG]
2)
16/6 16/6 35/2 35/2
Max. pre-fuses [A]
1
63 63 63 80
Estimated power loss
at rated max. load [W]
4)
382 454 513 721
Enclosure IP 21, IP 55
Weight,
enclosure IP 21, IP 55 [kg]
23 23 28 28
Efficiency
4)
0.98 0.98 0.98 0.98
58
