FC 300 Selection
" Line Supply 3 x 525 - 600 VAC (FC 302 only)
FC 302
Typ ical Shaft Out put [kW]
0.25 0.37 0.55 0.75 1.1 1.5 2.2 3 3.7 4 5.5 7.5
Output current
Continuous
(3 x 525-550 V) [A]
- - - 1.8 2.6 2.9 4.1 5.2 - 6.4 9.5 11.5
Intermittent
(3 x 525-550 V) [A]
- - - 2.9 4.2 4.6 6.6 8.3 - 10.2 15.2 18.4
Continuous
(3 x 525-600 V) [A]
- - - 1.7 2.4 2.7 3.9 4.9 - 6.1 9.0 11.0
Intermittent
(3 x 525-600 V) [A]
- - - 2.7 3.8 4.3 6.2 7.8 - 9.8 14.4 17.6
Continuous kVA (525 V AC)
[kVA]
- - - 1.7 2.5 2.8 3.9 5.0 - 6.1 9.0 11.0
Continuous kVA (575 V AC)
[kVA]
- - - 1.7 2.4 2.7 3.9 4.9 - 6.1 9.0 11.0
Max. cable size
(line, motor, brake)
[AWG]
2)
[mm
2
]
---
24 - 10 AWG
0.0079-0.1575 in [0.2-4 mm]
2
-
24 - 10 AWG
0.0079-0.1575 in
[0.2-4 mm]
2
Max. input current
Continuous
(3 x 525-600 V) [A]
- - - 1.7 2.4 2.7 4.1 5.2 - 5.8 8.6 10.4
Intermittent
(3 x 525-600 V) [A]
- - - 2.7 3.8 4.3 6.6 8.3 - 9.3 13.8 16.6
Max. pre-fuses
1)
[A] - - - 10 10 10 20 20 - 20 32 32
Environment
Estimated power loss
at rated max. load [W]
4)
- - - 35 50 65 92 122 - 145 195 261
Enclosure IP 20
Weight,
enclosure IP 20 [kg]
- - - 6.5 6.5 6.5 6.5 6.5 - 6.5 6.6 6.6
Efficiency
4)
- - - 0.97 0.97 0.97 0.97 0.97 - 0.97 0.97 0.97
1) For type of fuse, see section Fuses.
2) Am erican Wire Gauge.
3) Measured using 16.4 ft. [5 m] shielded motor cables at rated load and rated frequency.
4) The typical power loss is at n om inal load conditions and expecte d to be wi
thin +/-15%
(tolerance relates to variety in voltage and cable conditions).
Values are based on a typical motor efficiency (eff2/eff3 border line). Less efficient mo tors will
also add to the power loss in the adjustable frequency d rive and vice
versa.
If the switching frequency is raised from nominal, the power losses may rise significantly.
LCP and typical control card power consumption values are included. Further options and
customer load may add up to 30 W to the loss es. (Though typical, only 4
Wextrafora
fully loaded control card, or options for slot A or slot B, each).
Although measurem e n ts are made with state of the art equipment, som e measurement
inaccuracy must be allowed for (+/-5% ).
59
MG.33.B6.22 - VLT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
