FC 300 Design Guide
How to Program
16-14 Motor Curr en t
Range:
0.00 - 0.00 A
*
0.00A
Function:
View the motor current measured as a mean value,
IRMS. The value is filtered, and thus approx.
1.3 seconds may pass from when an input value
changes to w hen the data read-out values change.
16-15 Frequency [% ]
Range:
0.00 - 0.00 %
*
0.00%
Function:
View a two-byte word reporting the actual m otor
frequency (without resonance damp ening) as a
percentage (scale 0000-4000 Hex) o f par. 4-19
Max. Output Frequency. Set par. 9-16 index 1 to
send it with the Status Word instead of the MAV.
16-16 Torque
Range:
-3000.0 - 3000.0 N m
*
0.0Nm
Function:
Viewthetorquevaluewithsign,appliedtothemotor
shaft. Linearity is not exact between 160% motor
current a n d torque in relation to the rated torque.
Some motors supply more than 160% torque.
Consequently, the min. value and the max. value
will depend on the max. motor current as well as the
motor used. The value is filtered, and thus approx.
1.3 seconds may pass from when an input changes
value to when the data read-out values change.
16-17 Speed [RPM]
Range:
0-0RPM
*
0RPM
Function:
View the actual motor RPM. In open loop or
closed loop process control the motor RPM
is estimated. In sp eed closed loop modes
the motor RPM is measured.
16-18 Motor Thermal
Range:
0 - 100%
*
0%
Function:
View the calculated thermal load on the motor. The
cut-out limit is 100%. The basis for calculation
is the ETR function selected in par. 1-90.
16-19 KTY Sensor Temperature
Range:
32° - xxx°F [0 - xxx°C]
*
32°F [0°C]
Function:
Returning the current temperature from the
KTY sensor built into the motor.
16-20 Motor Angle
Range:
0 - 65535
*
0
Function:
View the current encoder/resolver angle offset
relative to the index position. The value range of
0-65535 corresponds to 0-2*pi (radians).
" 16-3* Drive Status
Parameters for reporting the status of the
adjustable frequency drive.
16-30 DC Link Voltage
Range:
0 - 10 000 V
*
0V
Function:
View a measured value. The value is filtered,
and thus approx. 1.3 seconds may pass from
when an input value changes to when t he
data read-out value changes.
16-32 Brake Energy /s
Range:
0.000 - 0.000 kW
*
0.000kW
Function:
View the brake power transmitted to an external
brake resistor, stated as an instantaneous value.
*
default setting ()display text []value for use in communication via serial communication port
246
MG.33.B
6.22 - V LT is a registered Danfoss trademark
