FC 300 Design Guide
How to Program
Select *Do not reset SLC [0] to retain
the programmed settings in all group 13
parameters (13-*).
" 13-1* Comparators
Used for comparing continuous variables (i.e. output
frequency, output current, analog input etc.) with
a fixed preset value. Com parators are evaluated
once in each scan interval. You can use the result
(TRUE or FALSE) directly to define an event (see
par. 13-51), or as Boolean input in a logic rule ( see
par. 13-40, 13-42, or 13-44). All parameters in
this p arameter group are array parameters with
index 0-3. Select index 0 to program Comparator
0, index 1 to program Com parator 1, and so on.
13-10 Comparator Oper a n d
Array [4]
Option:
*
DISABLED [0]
Reference [1]
Fe
edback
[2
]
Motor speed [3]
Motor curre nt [4]
Motor torque [5]
Motor power [6]
Motor voltage [7]
DC-link voltage [8]
Motor thermal [9]
VLT thermal [10]
Heatsink temp. [11]
Analog input AI53 [12]
Analog input AI54 [13]
Analog input AIFB10 [14]
Analog input AIS24V [15]
Analog input AICCT [17]
Pulse input FI29 [18]
Pulse input FI33 [19]
Alarm number [20]
Counter A [30]
Counter B [31]
Function:
Select the variable to b e monitored by
the comparator.
*False [0] (default setting) enters the fixed
value of FALSE in the logic rule.
True [1]. enters the fixed value TRUE
in the logic rule.
Running [2] See parameter group 5-3*
for further description.
In range [3] See parameter group 5-3*
for further description.
On reference [4] See parameter group 5-3*
for further description.
Torque limit [5] See parameter group 5-3*
for further description.
Current limit [6] See parameter group 5-3*
for further description.
Out of current range [7] See parameter group
5-3* for further description.
Below I low [8] See parameter group 5 -3*
for further description.
Above I high [9] S ee parameter group 5-3*
for further description.
Below frequency low [11] See parameter group
5-3* for further description.
Above frequency high [12] See parameter group
5-3* for further description.
Thermal warning [16] See parameter group
5-3* for further description.
Line voltage out of range [17] See parameter
group 5 -3* for further description.
Reversing [18] Se e p arameter group 5-3*
for further description.
Warning [19] See pa rameter group 5-3*
for further description.
Alarm (trip) [20] See parameter group 5-3*
for further description.
Alarm (trip lock) [21] See parameter group
5-3* for further description.
Comparator 0 [22] Use the result of comparator
0 in the logic rule.
Comparator 1 [23] Use the result of comparator
1 in the logic rule.
Comparator 2 [24] Use the result of comparator
2 in the logic rule.
Comparator 3 [25] Use the result of comparator
3 in the logic rule.
Logic rule 0 [26] Use the result of logic
rule 0 i n the logic rule.
Logic rule 1 [27] Use the result of logic
rule 1 i n the logic rule.
Logic rule 2 [28] Use the result of logic
rule 2 i n the logic rule.
Logic rule 3 [29] Use the result of logic
rule 3 i n the logic rule.
Digital input DI18 [33]UsethevalueofDI18
in the logic rule (High = TRUE).
*
default setting ()display text []value for use in communication via serial communication port
228
MG.33.B
6.22 - V LT is a registered Danfoss trademark
