Page #268 background imageLoading...
Page #268 background image
FC 300 Design Guide
How to Program
" 17-** Motor Feedb.Option
Par.
No.
#
Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Typ e
17-1* Inc. Enc. Interface
17-10Signal Type [1] TTL (5V, RS422) All set-ups FALSE - Uint8
17-11Resolution (PPR) 1024 N/A All set-ups FALSE 0 Uint16
17-2*Abs.Enc.Interface
17-20Protocol Selection [0] None All set-ups FALSE - Uint8
17-21Resolution (Positions/Rev) [32768] 32768 All set-ups FALSE - Uint16
17-34HIPERFACE Baud rate [4] 9600 All set-ups FALSE - Uint8
17-6* Monitoring and App.
17-60Encoder Positive Direction [0] Clockwise All set-ups FAL SE - Uint8
*
default setting ()display text []value for use in communication via serial communication port
268
MG.33.B
6.22 - V LT is a registered Danfoss trademark
