Table 73: Timer 2
Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.12.7.1
Duration
0
72000
s
0
1491
See Timer 1.
P3.12.7.2
Timer 2
DigINSlot 0.1
448
See Timer 1.
P3.12.7.3
Assign to Channel
1492
See Timer 1.
Table 74: Timer 3
Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.12.8.1
Duration
0
72000
s
0
1493
See Timer 1.
P3.12.8.2
Timer 3
DigINSlot 0.1
449
See Timer 1.
P3.12.8.3
Assign to Channel
1494
See Timer 1.
6.13 Group 3.13: PID Controller
Table 75: PID Controller Basic Settings
Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.13.1.1
PID Gain
0.00
1000.00
%
100.00
118
P3.13.1.2
PID Integration
Time
0.00
600.00
s
1.00
119
P3.13.1.3
PID Derivation
Time
0.00
100.00
s
0.00
132
P3.13.1.4
Process Unit Se-
lection
1
46
1
1036
1 = %
2 = 1/min
3 = RPM
4 = ppm
5 = pps
6 = l/s
7 = l/min
8 = l/h
9 = kg/s
10 = kg/min
11 = kg/h
12 = m
3
/s
13 = m
3
/min
14 = m
3
/h
15 = m/s
16 = mbar
17= bar
18 = Pa
19 = kPa
20 = mVS
21 = kW
