Index
Parameter
Min
Max
Unit
De-
fault
ID
Description
P3.21.5.5
Frost Protec-
tionTempera-
ture Limit
P3.21.5. 3
P3.21.5.4
°C/°F
5.00
(°C)
1708
P3.21.5.6
Frost Protec-
tion Frequen-
cy
0.0
P3.3.1.2
Hz
10.0
1710
P3.21.5.7
Frost Temper-
atureMonitor-
ing
Varies
Varies
°C/°F
1711
This monitoring value shows the value of the tem-
perature signal that is used for Frost Protection
function.
Table 104: Flow Switch Parameters
Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.21.6.1
Flow Switch
DigINSlot0.2
15590
P3.21.6.2
Flow Switch FaultDelay
0.0
3000.0
s
20.0
15585
P3.21.6.3
Flow Switch Bypass at Start
0.0
3000.0
s
20.0
15586
P3.21.6.4
Flow Switch Minimum Frequency
Varies
Varies
Hz
0.0
15587
6.21 Group 3.23: Advanced Harmonic Filter
Table 105: Advanced Harmonic Filter Parameters
Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.23.1
Cap Disconnect Limit
0
100
%
10
15510
P3.23.2
Cap Disconnect Hyst
0
100
%
10
15511
P3.23.3
AHF overtemperature
DigIN Slot0.1
15513
P3.23.4
AHF Fault Response
0
3
3
15512
0 = No Action
1 = Alarm
2 = Fault
3 = Fault, Coast
6.22 Group 3.24: Condition-based Monitoring
Table 106: Condition-based Monitoring Parameters
Index
Name
Min
Max
Unit
Default
ID
Description
P3.24.1
Condition Based Monitoring Fault Mode
0
2
1
3540
0=No Action
1=Warnings
2=Fault + Warnings
P3.24.2 Baseline Settings
P3.24.2.1
BaselineRun Start
0
1
0
3501
0=Disabled
1=Enabled
P3.24.2.2
BaselineRun MinFreq
Varies
Varies
Hz
0.00
3502
AB298035655957en-000201 / DPD01083130 | Danfoss A/S © 2023.08
Parameters Menu
VACON® 100 FLOW
Application Guide
