Parameter
Min
Max
Unit
Default
ID
Description
P3.8.6
Supervision #2 Mode
0
2
0
1436
See P3.8.2
P3.8.7
Supervision #2 Limit
-50.00
50.00
Varies
40.00
1437
P3.8.8
Supervision #2 Limit Hysteresis
0.00
50.00
Varies
5.00
1438
6.9 Group 3.9: Protections
Table 57: General Protection Settings
Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.9.1.2
Response to External Fault
0
3
2
701
0 = No action
1 = Alarm
2 = Fault (Stop according to stop func-
tion)
3 = Fault (Stop by coasting)
P3.9.1.3
Input Phase Fault
0
1
0
730
0 = 3-phase support
1 = 1-phase support
P3.9.1.4
Undervoltage Fault
0
1
0
727
0 = Fault stored in history
1 = Fault not stored in history
P3.9.1.5
Response to Output Phase
Fault
0
3
2
702
See P3.9.1.2.
P3.9.1.6
Response to Fieldbus Com-
munication Fault
0
5
4
733
0 = No action
1 = Alarm
2 = Alarm + preset fault frequency
(P3.9.1.13)
3 = Fault (Stop according to stop func-
tion)
4 = Fault (Stop by coasting)
P3.9.1.7
Slot Communication Fault
0
3
2
734
See P3.9.1.2.
P3.9.1.8
Thermistor Fault
0
3
0
732
See P3.9.1.2.
P3.9.1.9
PID Soft Fill Fault
0
3
2
748
See P3.9.1.2.
P3.9.1.10
Response to PID Supervision
Fault
0
3
2
749
See P3.9.1.2.
P3.9.1.11
Response to External PID Su-
pervision Fault
0
3
2
757
0 = No action
1 = Alarm
2 = Fault
3 = Fault, Coast
P3.9.1.12
Earth Fault
0
3
3
703
This parameter is available only in enclo-
sure sizes MR7, MR8, MR9, MR10, MR11,
and MR12, and also MR6 600 V and 690 V.
P3.9.1.13
Preset Alarm Frequency
P3.3.1.1
P3.3.1.2
Hz
25.00
183
AB298035655957en-000201 / DPD01083 | 105Danfoss A/S © 2023.08
Parameters Menu
VACON® 100 FLOW
Application Guide
