Parameter
Min
Max
Unit
Default
ID
Description
16 = Block Out.6
17 = Block Out.7
18 = Block Out.8
19 = Block Out.9
20 = Block Out.10
1.23
Keypad Control Refer-
ence Selection
1
20
1
121
See P1.22.
1.24
Fieldbus Control Ref-
erence Selection
1
20
2
122
See P1.22.
1.25
AI1 Signal Range
0
1
0
379
0= 0...10 V/0...20 mA
1= 2...10 V/4...20 mA
1.26
AI2 Signal Range
0
1
1
390
0= 0...10 V/0...20 mA
1= 2...10 V/4...20 mA
1.27
RO1 Function
0
74
2
11001
See P3.5.3.2.1.
1.28
RO2 Function
0
74
3
11004
See P3.5.3.2.1.
1.29
RO3 Function
0
74
1
11007
See P3.5.3.2.1.
1.30
AO1 Function
0
31
2
10050
See P3.5.4.1.1.
Table 6: M1.33 PID Control
Index
Parameter
Min
Max
Unit
Default
ID
Description
1.33.1
PID Gain
0.00
100.00
%
100.00
118
1.33.2
PID Integration Time
0.00
600.00
s
1.00
119
1.33.3
PID Derivation Time
0.00
100.00
s
0.00
132
1.33.4
Process Unit Selection
1
44
1
1036
See P3.13.1.4
1.33.5
Process Unit Min
Varies
Varies
Varies
1033
See P3.13.2.6.
1.33.6
Process Unit Max
Varies
Varies
Varies
1034
1.33.7
Feedback 1 Source Selection
0
30
2
334
See P3.13.3.3
1.33.8
Setpoint 1 Source Selection
0
32
1
332
See P3.13.2.6
1.33.9
Keypad Setpoint 1
Varies
Varies
Varies
0
167
1.33.10
SP1 Sleep Frequency Limit
0.0
320.0
Hz
0.0
1016
1.33.11
SP1 Sleep Delay
0
3000
s
0
1017
0 = Not used
1.33.12
SP1 Wake Up Level
Varies
Varies
Varies
Varies
1018
0 = Not used
1.33.13
Preset Frequency 1
P1.3
P1.4
Hz
10.0
105
3.4 Multi-pump (Single Drive) Application
Use the Multi-pump (single drive) application in applications, where 1 drive controls a system that has the maximum of 8 parallel
motors, for example, pumps, fans or compressors. By default, Multi-pump (single drive) application is configured for 3 parallel mo-
tors.
AB298035655957en-000201 / DPD01083 | 37Danfoss A/S © 2023.08
Applications
VACON® 100 FLOW
Application Guide
