12.

13.
14.
15.
16.

17.
18.
19.

20.
21.
22.

23.
24.
25.

1.

2.
3.
4.
5.
Set a value for P3.13.1.4 Process Unit Selection.
If the selection is other than %, the next steps are shown. If the selection is %, the wizard goes directly to step 16.
Set a value for P3.13.1.5 Process Unit Min.
The range depends on the selection in step 12.
Set a value for P3.13.1.6 Process Unit Max.
The range depends on the selection in step 12.
Set a value for P3.13.1.7 Process Unit Decimals.
Set a value for P3.13.3.3 Feedback 1 Source Selection.
See the table Feedback settings in chapter 6.13 Group 3.13: PID Controller.
If analog input signal is selected, step 18 is shown. With other selections, the wizard goes to step 19.
Set the signal range of the analog input.
Set a value for P3.13.1.8 Error Inversion.
Set a value for P3.13.2.6 Setpoint Source Selection.
See table Setpoints in chapter 6.13 Group 3.13: PID Controller.
If analog input signal is selected, step 21 is shown. With other selections, the wizard goes to step 23. If Keypad
Setpoint 1 or Keypad Setpoint 2 are set for the value, the wizard goes directly to step 22.
Set the signal range of the analog input.
Set a value for P3.13.2.1 (Keypad Setpoint 1) and P3.13.2.2 (Keypad Setpoint 2).
Depends on the range set in step 20.
Using the sleep function.
If value Yes is set for step 22, the next 3 steps are shown. If the value No is selected, the wizard is completed.
Set a value for P3.13.5.1 SP1 Sleep Frequency Limit.
Set a value for P3.13.5.2 SP1 Sleep Delay.
Set a value for P3.13.5.3 SP1 Wake-up Level.
The range depends on the set process unit.
The PID Control application wizard is completed.
4.1.4 Multi-pump (Single Drive) Application Wizard
The application wizard helps to set the basic parameters that are related to the application.
To start the Multi-pump (single drive application wizard, set the value PID Control to parameter P1.2 Application (ID 212) in the
keypad.
If the application wizard is started from the Start-up wizard, the wizard goes directly to step 11.
See the range of values of the parameters in 6.1 Group 3.1: Motor Settings, 6.3 Group 3.3: References, 6.4 Group 3.4: Ramps and
Brakes Setup, 6.13 Group 3.13: PID Controller.
Procedure
Set a value for P3.1.2.2 Motor Type (so that it agrees with the nameplate of the motor).
If Motor Type is set to Induction Motor, also step 6 is shown. If the selection is PM Motor, the value of parameter
P3.1.1.5 Motor Cos Phi is set to 1.00, and the wizard skips step 6.
Set a value for P3.1.1.1 Motor Nominal Voltage (so that it agrees with the nameplate of the motor).
Set a value for P3.1.1.2 Motor Nominal Frequency (so that it agrees with the nameplate of the motor).
Set a value for P3.1.1.3 Motor Nominal Speed (so that it agrees with the nameplate of the motor).
Set a value for P3.1.1.4 Motor Nominal Current (so that it agrees with the nameplate of the motor).
AB298035655957en-000201 / DPD0108370 | Danfoss A/S © 2023.08
Wizards
VACON® 100 FLOW
Application Guide
