5.14 Drive Customizer Monitoring
Table 26: Drive Customizer Monitoring
Index
Monitoring value
Unit
Scale
ID
Description
V2.13.2
Block Out.1
15020
V2.13.3
Block Out.2
15040
V2.13.4
Block Out.3
15060
V2.13.5
Block Out.4
15080
V2.13.6
Block Out.5
15100
V2.13.7
Block Out.6
15120
V2.13.8
Block Out.7
15140
V2.13.9
Block Out.8
15160
V2.13.10
Block Out.9
15180
V2.13.11
Block Out.10
15200
5.15 Condition-based Monitoring
Table 27: Condition-based Monitoring
Index
Name
Min
Max
Unit
Default
ID
Description
V2.16.1 Baseline Data
V2.16.1.1
BaselineDataElem1
-300.00
320.00
various
0.00
3601
V2.16.1.2
BaselineDataElem2
-300.00
320.00
various
0.00
3602
V2.16.1.3
BaselineDataElem3
-300.00
320.00
various
0.00
3603
V2.16.1.4
BaselineDataElem4
-300.00
320.00
various
0.00
3604
V2.16.1.5
BaselineDataElem5
-300.00
320.00
various
0.00
3605
V2.16.1.6
BaselineDataElem6
-300.00
320.00
various
0.00
3606
V2.16.1.7
BaselineDataElem7
-300.00
320.00
various
0.00
3607
V2.16.1.8
BaselineDataElem8
-300.00
320.00
various
0.00
3608
V2.16.1.9
BaselineDataElem9
-300.00
320.00
various
0.00
3609
V2.16.1.10
BaselineDataElem10
-300.00
320.00
various
0.00
3610
V2.16.1.11
BaselineRun Status
0
14
0
3622
0=Not Started
1=Running
2=Running 10%
3=Running 20%
4=Running 30%
5=Running 40%
6=Running 50%
7=Running 60%
8=Running 70%
9=Running 80%
