10.4.6 (ID 71) Temperature Input 6
Location in the menu: V2.5.6
This monitoring value shows the measured value of the temperature. The unit of the monitoring value is degrees Celsius or Fahren-
heit, depending on parameter C/F Selection (ID 1197) value.
10.5 Extras and Advanced
10.5.1 (ID 43) Drive Status Word
Location in the menu: V2.6.1
This monitoring value shows the bit-coded status of the drive.
10.5.2 (ID 78) Ready Status
Location in the menu: V2.6.2
This monitoring value shows the bit-coded data about the Ready criteria of the drive. This data is useful for monitoring when the
drive is not in the Ready state.
N O T I C E
The values are visible as checkboxes on the graphical display. If a box is selected, the value is active.
10.5.3 (ID 89) Application Status Word 1
Location in the menu: V2.6.3
This monitoring value shows the bit-coded statuses of the application.
N O T I C E
The values are visible as checkboxes on the graphical display. If a box is selected, the value is active.
10.5.4 (ID 90) Application Status Word 2
Location in the menu: V2.6.4
This monitoring value shows the bit-coded statuses of the application.
N O T I C E
The values are visible as checkboxes on the graphical display. If a box is selected, the value is active.
10.5.5 (ID 56) DIN Status Word 1
Location in the menu: V2.6.5
This monitoring value shows the bit-coded status of the digital input signals.
The monitoring value is a 16-bit word, where each bit shows the status of 1 digital input. From each slot, 6 digital inputs are read.
Word 1 starts from the input 1 in slot A (bit0) and ends with input 4 in slot C (bit15).
10.5.6 (ID 57) DIN Status Word 2
Location in the menu: V2.6.6
This monitoring value shows the bit-coded status of the digital input signals.
The monitoring value is a 16-bit word, where each bit shows the status of 1 digital input. From each slot, 6 digital inputs are read.
Word 2 starts from the input 5 in slot C (bit0) and ends with input 6 in slot E (bit13).
10.5.7 (ID 45) Motor Current 1 Deci
Location in the menu: V2.6.7
This monitoring value shows the measured current of the motor with the fixed number of decimals and that is less filtered. This
monitoring value can be used, for example, with fieldbus to get the correct value so that the enclosure size does not have an effect.
It can also be used for monitoring when less filtering time is needed for the motor current.
AB298035655957en-000201 / DPD01083 | 155Danfoss A/S © 2023.08
Monitoring Value Descriptions
VACON® 100 FLOW
Application Guide
