2.3.5.2 Changing the Control Place
This topic gives instructions on how to change the control place on the control panel.
Procedure
Anywhere in the menu structure, push the [FUNCT] button.
To select Local/Remote, use the arrow buttons Up and Down. Push the [OK] button.
STOP
READY Keypad
ID:1805
Choose action
Control page
Change direction
Local/Remote
e30bu027.10
To select Local or Remote, use the arrow buttons Up and Down again. To accept the selection, push the [OK] button.
STOP
READY Keypad
ID:211
Local/Remote
Remote
Local
e30bu028.10
If Remote control place is changed to Local, that is, Keypad, give a keypad reference.
After the selection, the display goes back into the same location where it was when the [FUNCT] button was push-
ed.
2.3.5.3 Going into the Control Page
It is easy to monitor the most important values in the Control page.
See more information about Keypad Reference in
6.3 Group 3.3: References. If other control places or reference values are used, the
display shows the frequency reference, which cannot be edited. The other values on the page are Multimonitor values. These values
can be selected (see 5.2.1 Changing the Items to Monitor).
Procedure
Anywhere in the menu structure, push the [FUNCT] button.
To select the Control page, push the arrow buttons Up and Down. Go in with the [OK] button.
The Control page opens.
With the Local control place and the keypad reference selected, P3.3.1.8 Keypad Reference can be set with the [OK] button.
AB298035655957en-000201 / DPD0108320 | Danfoss A/S © 2023.08
User Interfaces
VACON® 100 FLOW
Application Guide
