Table 33: Torque Stabilator Parameters
Index
Parameter
Min
Max
Unit
Default
ID
Descrip-
tion
P3.1.4.13.1
Torque Stabilator Gain
0.0
500.0
%
50.0
1412
P3.1.4.13.2
Torque Stabilator Gain at Field Weakening Point
0.0
500.0
%
50.0
1414
P3.1.4.13.3
Torque Stabilator Damping Time Constant
0.0005
1.0000
s
0.0050
1413
P3.1.4.13.4
Torque Stabilator Damping Time Constant for PM motors
0.0005
1.0000
s
0.0500
1735
P3.1.4.13.5
Torque Stabilator Filter Time Constant
0.0000
0.5000
s
0.0005
15650
P3.1.4.13.6
Torque Stabilator Filter Time Constant for PM motors
0.0000
0.5000
s
0.0005
15651
6.2 Group 3.2: Start/Stop Setup
Table 34: Start/Stop Setup
Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.2.1
Remote Control Place
0
1
0
(1)
172
0 = I/O control
1 = Fieldbus control
P3.2.2
Local/Remote
0
1
0
(1)
211
0 = Remote
1 = Local
P3.2.3
Keypad Stop Button
0
1
0
114
0 = Yes
1 = No
P3.2.4
Start Function
0
1
0
505
0 = Ramping
1 = Flying start
P3.2.5
Stop Function
0
1
0
506
0 = Coasting
1 = Ramping
P3.2.6
I/O A Start/Stop Logic
0
4
2
(1)
300
Logic = 0
Ctrl sgn 1 = Forward
Ctrl sgn 2 = Backward
Logic = 1
Ctrl sgn 1 = Forward (edge)
Ctrl sgn 2 = Inverted Stop
Ctrl sgn 3 = Bckwrd (edge)
Logic = 2
Ctrl sgn 1 = Forward (edge)
Ctrl sgn 2 = Bckwrd (edge)
Logic = 3
Ctrl sgn 1 = Start
Ctrl sgn 2 = Reverse
Logic = 4
AB298035655957en-000201 / DPD0108390 | Danfoss A/S © 2023.08
Parameters Menu
VACON® 100 FLOW
Application Guide
