Danfoss VACON 100 FLOW Series User Manual

6 Parameters Menu
6.1 Group 3.1: Motor Settings
Table 28: Motor Nameplate Parameters
Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.1.1.1
Motor Nominal Voltage
Varies
Varies
V
Varies
110
P3.1.1.2
Motor Nominal Frequency
8.00
320.00
Hz
50 / 60
111
P3.1.1.3
Motor Nominal Speed
24
19200
rpm
Varies
112
P3.1.1.4
Motor Nominal Current
IH * 0.1
IH * 2
A
Varies
113
P3.1.1.5
Motor Cos Phi (Power Factor)
0.30
1.00
Varies
120
P3.1.1.6
Motor Nominal Power
Varies
Varies
kW
Varies
116
Table 29: Motor Control Settings
Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.1.2.2
Motor Type
0
2
0
650
0 = Induction motor
1 = PM motor
2 = Reluctance motor
P3.1.2.3
Switching Frequency
1.5
Varies
kHz
Varies
601
P3.1.2.4
Identification
0
2
0
631
0 = No action
1 = At standstill
2 = With rotation
P3.1.2.5
Magnetizing Current
0.0
2*IH
A
0.0
612
P3.1.2.6
Motor Switch
0
1
0
653
0 = Disabled
1 = Enabled
P3.1.2.10
Overvoltage Control
0
1
1
607
0 = Disabled
1 = Enabled
P3.1.2.11
Undervoltage Control
0
1
1
608
0 = Disabled
1 = Enabled
P3.1.2.12
Energy Optimization
0
1
0
666
0 = Disabled
1 = Enabled
P3.1.2.13
Stator Voltage Adjust
50.0
150.0
%
100.0
659
P3.1.2.15
Rs Voltage Drop
0.00
50.00
%
0.00
662
P3.1.2.16
Ls Voltage Drop
0.00
200.00
%
0.00
673
P3.1.2.17
Motor BEM Voltage
0
Varies
V
0
674
AB298035655957en-000201 / DPD0108388 | Danfoss A/S © 2023.08
Parameters Menu
VACON® 100 FLOW
Application Guide
