10.5.8 (ID 1495) Frequency Reference Source
Location in the menu: V2.6.8
This monitoring value shows the momentary frequency reference source.
10.5.9 (ID 37) Last Active Fault Code
Location in the menu: V2.6.9
This monitoring value shows the fault code of latest activated fault that is not reset.
10.5.10 (ID 95) Last Active Fault ID
Location in the menu: V2.6.10
This monitoring value shows the fault ID of latest activated fault that is not reset.
10.5.11 (ID 74) Last Active Alarm Code
Location in the menu: V2.6.11
This monitoring value shows the alarm code of latest activated alarm that is not reset.
10.5.12 (ID 94) Last Active Alarm ID
Location in the menu: V2.6.12
This monitoring value shows the alarm ID of latest activated alarm that is not reset.
10.5.13 (ID 77) Motor Regulator Status
Location in the menu: V2.6.13
This monitoring value shows the bit-coded status of the motor limit controllers.
N O T I C E
The values are visible as checkboxes on the graphical display. If a box is selected, the limit controller is active.
10.5.14 (ID 98) Motor Shaft Power 1 Decimal
Location in the menu: V2.6.14
This monitoring value shows the actual shaft power of the motor (calculated value with one decimal). The unit of measurement is
kW or hp, depending on parameter kW/hp Selection (ID 1198) value.
10.6 Timer Functions
10.6.1 (ID 1441) TC 1, TC 2, TC 3
Location in the menu: V2.7.1
This monitoring value shows the status of the time channels 1, 2 and 3.
10.6.2 (ID 1442) Interval 1
Location in the menu: V2.7.2
This monitoring value shows the status of the interval function.
10.6.3 (ID 1443) Interval 2
Location in the menu: V2.7.3
This monitoring value shows the status of the interval function.
10.6.4 (ID 1444) Interval 3
Location in the menu: V2.7.4
This monitoring value shows the status of the interval function.
10.6.5 (ID 1445) Interval 4
Location in the menu: V2.7.5
AB298035655957en-000201 / DPD01083156 | Danfoss A/S © 2023.08
Monitoring Value Descriptions
VACON® 100 FLOW
Application Guide
