Index
Monitoring value
Unit
Scale
ID
Description
V2.8.5
PID Error
Varies
As is set in P3.13.1.7
22
V2.8.6
PID Output
%
0.01
23
V2.8.7
PID Status
1
24
0 = Stopped
1 = Running
3 = Sleep mode
4 = In dead band (see 6.13 Group
3.13: PID Controller)
5.10 External PID Controller Monitoring
Table 20: Monitoring of the Values of the External PID Controller
Index
Monitoring value
Unit
Scale
ID
Description
V2.9.1
ExtPID Setpoint
Varies
As set in P3.14.1.10 (See 6.14 Group 3.14:
External PID Controller.)
83
V2.9.2
ExtPID Feedback
Varies
As set in P3.14.1.10
84
V2.9.3
ExtPID Error
Varies
As set in P3.14.1.10
85
V2.9.4
ExtPID Output
%
0.01
86
V2.9.5
ExtPID Status
1
87
0 = Stopped
1 = Running
2 = In dead band (See 6.14 Group 3.14:
External PID Controller.)
5.11 Multi-pump Monitoring
Table 21: Multi-pump Monitoring
Index
Monitoring value
Unit
Scale
ID
Description
V2.10.1
Motors Running
1
30
V2.10.2
Autochange
1
1114
V2.10.3
Next Autochange
h
0.1
1503
V2.10.4
Operate Mode
1
1505
0 = Slave
1 = Master
V2.10.5
Multi-pump Status
1
1628
0 = Not used
10 = Stopped
20 = Sleep
30 = Anti-blocking
40 = Auto-cleaning
50 = Flushing60 = Soft filling 70 = Regulating
80 = Following
90 = Const. producing200 = Unknown
V2.10.6
CommunicationStatus
h
0.1
1629
0 = Not used (Multi-pump multidrive function)
10 = Fatal communication errors occurred (or no communication)
11 = Errors occurred (data sending)
AB298035655957en-000201 / DPD0108382 | Danfoss A/S © 2023.08
Monitor Menu
VACON® 100 FLOW
Application Guide
