Parameter
Min
Max
Unit
Default
ID
Description
16 = Block Out.6
17 = Block Out.7
18 = Block Out.8
19 = Block Out.9
20 = Block Out.10
1.23
Keypad Control Refer-
ence Selection
1
20
1
121
See P1.22.
1.24
Fieldbus Control Ref-
erence Selection
1
20
2
122
See P1.22.
1.25
AI1 Signal Range
0
1
0
379
0= 0...10 V/0...20 mA
1= 2...10 V/4...20 mA
1.26
AI2 Signal Range
0
1
1
390
0= 0...10 V/0...20 mA
1= 2...10 V/4...20 mA
1.27
RO1 Function
0
74
2
11001
See P3.5.3.2.1.
1.28
RO2 Function
0
74
3
11004
See P3.5.3.2.1.
1.29
RO3 Function
0
74
1
11007
See P3.5.3.2.1.
1.30
AO1 Function
0
31
2
10050
See P3.5.4.1.1.
Table 4: M1.31 Standard/M1.32 HVAC
Index
Parameter
Min
Max
Unit
Default
ID
Description
1.31.1
Preset Frequency 1
P1.3
P1.4
Hz
10.0
105
1.31.2
Preset Frequency 2
P1.3
P1.4
Hz
15.0
106
1.31.3
Preset Frequency 3
P1.3
P1.4
Hz
20.0
126
3.3 PID Control Application
Use the PID control application with processes where the process variable (for example pressure) is controlled through control of
the speed of the motor.
In this application, the internal PID controller of the drive is configured for 1 setpoint and 1 feedback signal.
It is possible to use 2 control places. Make the selection of the control place A or B with DI6. When control place A is active, the start/
stop commands are given by DI1, and the PID controller gives the frequency reference. When control place B is active, start/stop
commands are given by DI4, and AI1 gives the frequency reference.
It is possible to configure all the drive outputs freely in all the applications. There are 1 analog output (Output Frequency) and 3
relay outputs (Run, Fault, Ready) available on the basic I/O board.
AB298035655957en-000201 / DPD01083 | 33Danfoss A/S © 2023.08
Applications
VACON® 100 FLOW
Application Guide
