Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.16.3
Counter 1 Fault Limit
0
2147483647
h/kRev
0
1106
0 = Not used
P3.16.4
Counter 1 Reset
0
1107
P3.16.5
Counter 1 DI Reset
0
490
CLOSED = Reset
6.17 Group 3.17: Fire Mode
Table 96: Fire Mode Parameters
Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.17.1
Fire Mode Password
0
9999
0
1599
1001 = Enabled
1234 = Test mode
P3.17.2
Fire Mode Frequency Source
0
18
0
1617
0 = Fire Mode frequency
1 = Preset speeds
2 = Keypad
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1 + AI2
7 = PID1
8 = Motor potentiometer
9 = Block Out.1
10 = Block Out.2
11 = Block Out.3
12 = Block Out.4
13 = Block Out.5
14 = Block Out.6
15 = Block Out.7
16 = Block Out.8
17 = Block Out.9
18 = Block Out.10
P3.17.3
Fire Mode Frequency
0.00
P3.3.1.2
Hz
50.00
1598
P3.17.4
Fire Mode Activation on
OPEN
DigIN Slot0.2
1596
OPEN = Fire Mode active
CLOSED = No action
P3.17.5
Fire Mode Activation on
CLOSE
DigIN Slot0.1
1619
OPEN = No action
CLOSED = Fire Mode active
P3.17.6
Fire Mode Reverse
DigIN Slot0.1
1618
OPEN = Forward
CLOSED = Reverse
DigIN Slot0.1 = Forward
DigIN Slot0.2 = Reverse
V3.17.7
Fire Mode Status
0
3
1597
0 = Disabled
1 = Enabled
2 = Activated (Enabled + DI Open)
AB298035655957en-000201 / DPD01083126 | Danfoss A/S © 2023.08
Parameters Menu
VACON® 100 FLOW
Application Guide
