Parameter
Min
Max
Unit
Default
ID
Description
1.11
Motor Nominal Speed
24
19200
RPM
Varies
112
Find this value n
n
on the nameplate of the mo-
tor.
1.12
Motor Nominal Cur-
rent
IH * 0.1
IH * 2
A
Varies
113
Find this value I
n
on the nameplate of the mo-
tor.
1.13
Motor Cos Phi (Power
Factor)
0.30
1.00
Varies
120
Find this value on the nameplate of the motor.
1.14
Energy Optimization
0
1
0
666
0 = Disabled
1 = Enabled
1.15
Identification
0
2
0
631
0 = No action
1 = At standstill
2 = With rotation
1.16
Start Function
0
1
0
505
0 = Ramping
1 = Flying Start
1.17
Stop Function
0
1
0
506
0 = Coasting
1 = Ramping
1.18
Automatic Reset
0
1
0
731
0 = Disabled
1 = Enabled
1.19
Response to External
Fault
0
3
2
701
0 = No action
1 = Alarm
2 = Fault (Stop according to stop mode)
3 = Fault (Stop by coasting)
1.20
Response to AI Low
Fault
0
5
0
700
0 = No action
1 = Alarm
2 = Alarm+preset fault frequency (P3.9.1.13)
3 = Alarm + previous frequency
4 = Fault (Stop according to stop mode)
5 = Fault (Stop by coasting)
1.21
Remote Control Place
0
1
0
172
0 = I/O control
1 = Fieldbus control
1.22
I/O Control Reference
A Selection
1
20
5
117
1 = Preset Frequency 0
2 = Keypad reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID reference
8 = Motor potentiometer
11 = Block Out.1
12 = Block Out.2
13 = Block Out.3
14 = Block Out.4
15 = Block Out.5
