Danfoss VACON 100 FLOW Series - Page 86

Index
Name
Min
Max
Unit
Default
ID
Description
10=Running 90%
11=Completed
12=Run Failed
13=Manual Before Baseline
14=Manual After Baseline
V2.16.2 Stator Winding Monitor
V2.16.2.1
Current Unbalance
0.00
100.00
%
0.00
3617
V2.16.2.2
Current Threshold Value
0.00
100.00
%
0.00
3620
V2.16.2.3
Current Warning S1 High Threshold
0.00
100.00
%
0.00
3611
V2.16.2.4
Current Warning S2 High Threshold
0.00
100.00
%
0.00
3612
V2.16.2.5
Current Alarm High Threshold
0.00
100.00
%
0.00
3613
V2.16.3 Vibration
V2.16.3.1
Vibration
0.00
100.00
%
0.00
3623
V2.16.3.2
Vibration Threshold Value
0.00
100.00
%
0.00
3624
V2.16.3.3
Vibration Warning S1 High Thresh-
old
0.00
100.00
%
0.00
3625
V2.16.3.4
Vibration Warning S2 High Thresh-
old
0.00
100.00
%
0.00
3626
V2.16.3.5
Vibration Alarm High Threshold
0.00
100.00
%
0.00
3627
V2.16.4 Load
V2.16.4.1
Motor Torque
-300.0
300.0
%
0.0
4
V2.16.4.2
Load Threshold Value
-300.0
300.0
%
0.00
3628
V2.16.4.3
Load Warning S1 High Threshold
-300.0
300.0
%
0.00
3629
V2.16.4.4
Load Warning S2 High Threshold
-300.0
300.0
%
0.00
3630
V2.16.4.5
Load Alarm High Threshold
-300.0
300.0
%
0.00
3631
V2.16.4.6
Load Warning S1 Low Threshold
-300.0
300.0
%
0.00
3632
V2.16.4.7
Load Warning S2 Low Threshold
-300.0
300.0
%
0.00
3633
V2.16.4.8
Load Alarm Low Threshold
-300.0
300.0
%
0.00
3634
V2.16.5
Condition Based Monitoring Status
0
65535
0
3619
B0= Stator current warning S1
B2= Vibration warning S1
B3= Load warning S1
B5= Stator current warning S2
B7= Vibration warning S2
B8= Load warning S2
B10= Stator current alarm/
fault
B12= Vibration alarm/fault
AB298035655957en-000201 / DPD0108386 | Danfoss A/S © 2023.08
Monitor Menu
VACON® 100 FLOW
Application Guide
