Set a value for P3.1.1.5 Motor Cos Phi (so that it agrees with the nameplate of the motor).
Set a value for P3.3.1.1 Minimum Frequency Reference.
Set a value for P3.3.1.2 Maximum Frequency Reference.
Set a value for P3.4.1.2 Acceleration Time 1.
Set a value for P3.4.1.3 Deceleration Time 1.
Select a control place (where to give the start and stop commands, and the frequency reference of the drive).
Set a value for P3.13.1.4 Process Unit Selection.
If the selection is other than %, the next steps are shown. If the selection is %, the wizard goes directly to step 16.
Set a value for P3.13.1.5 Process Unit Min.
Set a value for P3.13.1.6 Process Unit Max.
Set a value for P3.13.1.7 Process Unit Decimals.
Set a value for P3.13.3.3 Feedback 1 Source Selection.
See the table Feedback settings in chapter 6.13 Group 3.13: PID Controller.
If analog input signal is selected, step 17 is shown. With other selections, the wizard goes to step 18.
Set the signal range of the analog input.
See table Analog inputs in chapter 6.5 Group 3.5: I/O Configuration.
Set a value for P3.13.1.8 Error Inversion.
Set a value for P3.13.2.6 Setpoint Source Selection.
See table Setpoints in chapter 6.13 Group 3.13: PID Controller.
If analog input signal is selected, step 20 is shown. With other selections, the wizard goes to step 21. If Keypad
Setpoint 1 or Keypad Setpoint 2 is selected for the value, step 22 is shown.
Set the signal range of the analog input.
See table Analog inputs in chapter 6.5 Group 3.5: I/O Configuration.
Set a value for P3.13.2.1 (Keypad setpoint 1) and P3.13.2.2 (Keypad setpoint 2).
Using the sleep function.
If the value "Yes" is given step 22, the next 3 steps are shown.
Set a value for P3.13.5.1 SP1 Sleep Frequency Limit.
Set a value for P3.13.5.2 SP1 Sleep Delay.
Set a value for P3.13.5.3 SP1 Wake-up Level.
Set a value for P3.15.2 Number of pumps.
Set a value for P3.15.5 Pump Interlocking.
Set a value for P3.15.6 Autochange.
If the value Enabled (Interval or Weekdays) is set to parameter Autochange, the next 6 steps are shown. If the Au-
tochange function is not used, the wizard goes directly to step 21.
Set a value for P3.15.7 Autochanged pumps.
If the value Enabled (Interval) is set to parameter Autochange in step 28, the next step is shown.
Set a value for P3.15.8 Autochange Interval.
If the value Enabled (Weekdays) is set to parameter Autochange in step 28, the next 2 steps are shown.
Set a value for P3.15.9 Autochange Days.
Set a value for P3.15.10 Autochange Time of Day.
Set a value for P3.15.11 Autochange Frequency Limit.
Set a value for P3.15.12 Autochange Pump Limit.
AB298035655957en-000201 / DPD01083 | 71Danfoss A/S © 2023.08
Wizards
VACON® 100 FLOW
Application Guide
