Index
Parameter
Min
Max
Unit
Default
ID
Description
24 = Block Out.2
25 = Block Out.3
26 = Block Out.4
27 = Block Out.5
28 = Block Out.6
29 = Block Out.7
30 = Block Out.8
31 = Block Out.9
32 = Block Out.10
If temperature inputs are selected, the values
of parameters P3.14.1.8 Process Unit Min and
P3.14.1.9 Process Unit Max must be set to
correspond to the scale of the temperature
measurement board.
P3.14.2.6
Setpoint 1 min-
imum
-200.00
200.00
%
0.00
1644
P3.14.2.7
Setpoint 1 max-
imum
-200.00
200.00
%
100.00
1645
P3.14.2.8
Setpoint source
2 selection
0
32
2
1646
See P3.14.2.5.
P3.14.2.9
Setpoint 2 min-
imum
-200.00
200.00
%
0.00
1647
P3.14.2.10
Setpoint 2 max-
imum
-200.00
200.00
%
100.00
1648
Table 88: Feedback of the External PID Controller
Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.14.3.1
Feedback Function
1
9
1
1650
See P3.13.3.1
P3.14.3.2
Feedback Function Gain
-1000.0
1000.0
%
100.0
1651
See P3.13.3.2
P3.14.3.3
Feedback 1 Source Selection
0
30
2
1652
See P3.13.3.3
P3.14.3.4
Feedback 1 Minimum
-200.00
200.00
%
0.00
1653
P3.14.3.5
Feedback 1 Maximum
-200.00
200.00
%
100.00
1654
P3.14.3.6
Feedback 2 Source Selection
0
30
0
1655
See P3.13.3.6.
P3.14.3.7
Feedback 2 Minimum
-200.00
200.00
%
0.00
1656
P3.14.3.8
Feedback 2 Maximum
-200.00
200.00
%
100.00
1657
