Index
Monitoring value
Unit
Scale
ID
Description
B12 = Motor Preheat active
B13 = Quick stop active
B14 = Drive stopped from keypad
V2.6.4
Application Status Word2
1
90
B0 = Acc/Dec prohibited
B1 = Motor switch open
B2 = PID running
B3 = PID sleep
B4 = PID soft fil
B5 = Autocleaning active
B6 = Jockey pump
B7 = Priming pump
B8 = Anti-blocking
B9 = Input pressure alarm
B10 = Frost protection alarm
B11 = Overpressure alarm
B14 = Supervision 1
B15 = Supervision 2
V2.6.5
DIN Status Word 1
1
56
V2.6.6
DIN Status Word 2
1
57
V2.6.7
Motor current 1 decimal
0.1
45
V2.6.8
Frequency reference source
1
1495
0 = PC
1 = Preset Freqs
2 = Keypad Reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID Controller
8 = Motor Potentiom.
10 = Flushing
11 = Block Out.1
12 = Block Out.2
13 = Block Out.3
14 = Block Out.4
15 = Block Out.5
16 = Block Out.6
17 = Block Out.7
18 = Block Out.8
19 = Block Out.9
20 = Block Out.10
100 = Not defined
101 = Alarm,PresetFreq
102 = Auto-cleaning
V2.6.9
Last active fault code
1
37
V2.6.10
Last active fault ID
1
95
