FC 202 N630 N710 N800
Typical shaft output at 575 V [hp] 600 650 650 750 750 950
Typical shaft output at 690 V [kW] 560 630 630 710 710 800
Enclosure size E5h E6h E6h
Output current (3-phase)
Continuous (at 550 V) [A] 596 630 659 763 763 889
Intermittent (60 s overload) (at 550 V) [A] 894 693 989 839 1145 978
Continuous (at 575/690 V) [A] 570 630 630 730 730 850
Intermittent (60 s overload) (at 575/690 V) [A] 855 693 945 803 1095 935
Continuous kVA (at 550 V) [kVA] 568 600 628 727 727 847
Continuous kVA (at 575 V) [kVA] 568 627 627 727 727 847
Continuous kVA (at 690 V) [kVA] 681 753 753 872 872 1016
Maximum input current
Continuous (at 550 V) [A] 574 607 635 735 735 857
Continuous (at 575/690 V) [A] 549 607 607 704 704 819
Maximum number and size of cables per phase
- Mains [mm
2
(AWG)]
4x120 (4x250 mcm) 4x185 (4x350 mcm) 4x185 (4x350 mcm)
- Mains with disconnect [mm
2
(AWG)]
4x120 (4x250) 4x185 (4x350 mcm) 4x185 (4x350 mcm)
- Mains with fusible disconnect [mm
2
(AWG)]
4x120 (4x250) 4x185 (4x350 mcm) 4x185 (4x350 mcm)
- Mains with contactor [mm
2
(AWG)]
4x120 (4x250) 4x185 (4x350 mcm) 4x185 (4x350 mcm)
- Motor [mm
2
(AWG)]
4x120 (4x250) 4x185 (4x350 mcm) 4x185 (4x350 mcm)
Drive module power loss at 600 V [W]
(1) (2) (3)
8069 9208 8543 10346 10319 12723
Drive module power loss at 690 V [W]
(1) (2) (3)
7848 8921 8363 10066 10060 12321
Drive efficiency
(2)
0.98 0.98 0.98
Output frequency [Hz]
(4)
0–590 0–590 0–590
Heat sink overtemperature trip [°C (°F)] 110 (230) 110 (230) 110 (230)
Control card overtemperature trip [°C (°F)] 80 (176) 80 (176) 80 (176)
PHF overtemperature trip [°C (°F)] 150 (302) 150 (302) 150 (302)
dU/dt filter overtemperature trip [°C (°F)] 150 (302) 150 (302) 150 (302)
Sine-wave filter overtemperature trip [°C (°F)] 150 (302) 150 (302) 150 (302)
1
Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions.) These values are based on a typical motor
efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the drive. Applies to dimensioning of drive cooling. If the switching frequency is higher than the default
setting, the power losses can increase. LCP and typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/
knowledge-center/energy-efficiency-directive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B
each add only 4 W.
2
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Efficiency measured at nominal current. For energy efficiency class, see the Ambient Conditions
section. For part load losses, see drives.danfoss.com/knowledge-center/energy-efficiency-directive/#/.
Specifications
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882 | 169
Danfoss A/S © 2018.10
