Danfoss VLT AQUA Drive FC 202 User Manual

e30bf228.10
L1
L2
L3
PE
PE
u
v
w
2
1
3
5
16
17
18
14
12
8
7
10
9
4
11
13
4
4
6
15
90
1 Programmable logic controller (PLC)
3 Control cables
5 Mains supply
7 Star washers
9 Motor cable (shielded)
2
Minimum 16 mm
2
(6 AWG) equalizing cable
4 Minimum 200 mm (7.9 in) between control cables, motor
cables, and mains cables
6 Bare (unpainted) surface
8 Brake cable (shielded)
10 Mains cable (unshielded)
Electrical Installation
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882
44 | Danfoss A/S © 2018.10
