11 Output contactor, and so on.
13 Common ground busbar. Follow local and national
requirements for cabinet grounding.
15 Metal box
17 Motor
12 Cable insulation stripped
14 Brake resistor
16 Connection to motor
18 EMC cable gland
Illustration 20: Example of Proper EMC Installation
Electrical Installation
Operating Guide | VLT® AQUA Drive FC 202
AQ262141056213en-000101 / 130R0882 | 45
Danfoss A/S © 2018.10
