2. Replace the (M2x3) screw to secure the left Type-C board to the computer chassis.
3. Replace the three (M2.3x5) screws to secure the left Type-C board holder to the computer chassis.
4. Connect the flat printed cable to its connector on the left Type-C board.
5. Connect the left Type-C cable to its connector on the left Type-C board.
6. Replace the (M2.3x5) screw that secures the flat printed cable holder to the left Type-C board.
Next steps
1. Install the heat sink .
2. Install the fan.
3. Install the dock I/O-bracket.
4. Install the dock I/O-module.
5. Install the WWAN card.
6. Install the WLAN card.
7. Install the RF switch board.
8. Install the rear I/O-board.
9. Install the GPS board.
10. Install the base cover.
11. Install the keyboard (rubberized) or keyboard (standard).
12. Install the solid state drive carrier.
13. Install the batteries.
14. Follow the procedure in after working inside your computer.
Latch doors
Removing the latch doors
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in before working inside your computer.
About this task
The following image indicates the location of the latch doors and provides a visual representation of the removal procedure.
Removing and installing Field Replaceable Units (FRUs)
143
