Figure 10. Torx T8 screw
●
5.5 mm socket wrench
Figure 11. 5.5 mm Socket screw
● Plastic scribe
Screw list
NOTE:
When removing screws from a component, it is recommended to note the screw type and the quantity of screws,
and then place them in a screw storage box. This is to ensure that the correct number of screws and correct screw type is
restored when the component is replaced.
NOTE: Some computers have magnetic surfaces. Ensure that the screws are not left attached to such surfaces when
replacing a component.
NOTE: Screw color may vary depending on the configuration ordered.
Table 41. Screw list
Component Screw type Quantity Screw image
Solid state drive carrier M2x3 1
M.2 2230 solid state drive M2x2
M2x5
1
1
M.2 2280 solid state drive M2x5 1
44 Working inside your computer
