Steps
1. Align the screw holes on the GPS board with the screw holes on the system board.
2. Replace the two (M2.5x5) screws that secure the GPS board with the computer chassis.
3. Connect the GPS flat-printed cable to the connector on the GPS board.
4. Connect the GPS antenna cable on the GPS board.
NOTE: Adhere the GPS flat printed cable with kapton tapes to the connector.
Next steps
1. Install the base cover.
2. Install the solid state drive carrier.
3. Install the batteries.
4. Follow the procedure in after working inside your computer.
Rear I/O-board
Removing the rear I/O-board
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the batteries.
3. Remove the solid state drive carrier.
4. Remove the base cover.
About this task
The following image indicates the location of the rear I/O-board and provides a visual representation of the removal procedure.
Removing and installing Field Replaceable Units (FRUs)
93
