Global Positioning System (GPS) board
Removing the GPS board
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the batteries.
3. Remove the solid state drive carrier.
4. Remove the base cover.
About this task
The following image indicates the location of the GPS board and provides a visual representation of the removal procedure.
Figure 58. Removing the GPS board
Removing and installing Field Replaceable Units (FRUs)
91
