Figure 107. Installing the latch doors
Steps
1. Align the latch doors to the screw holes on the computer chassis.
2. Replace the 11 (M2x3) screws that secure the latch doors to the computer chassis.
Next steps
1. Follow the procedure in after working inside your computer.
Display assembly
Removing the display assembly
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in before working inside your computer.
Removing and installing Field Replaceable Units (FRUs)
145
