Table 42. Cable connectors on Dell Pro Rugged 13 RA13250(continued)
Cable number Antenna
11 GPS antenna
14 GPS antenna
4 GPS antenna
2. Peel the adhesive tape and disconnect the flexible printed cable from the RF switch board.
3. Remove the two (M2.5x5) screws that secure the RF switch board to the system board.
4. Lift the RF switch board from the system board.
Installing the RF switch board
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the RF switch board and provides a visual representation of the installation
procedure.
Removing and installing Field Replaceable Units (FRUs)
99
