Table 11. WWAN module specifications(continued)
Description Option one Option two
Frequency bands supported
● NR (n1, n2, n3, n5, n7, n8, n12, n13,
n14, 18, n20, n25, n26, n28, n30, n38,
n40, n41, n48, n53, n66, n70, n71,
n75, n76, n77, n78, n79)
● LTE (B1, B2, B3, B4, B5, B7, B8, B12,
B13, B14, B17, B18, B19, B20, B25,
B26, B28, B29, B30, B32, B34, B38,
B39, B40, B41, B42, B43, B46, B48,
B66, B71)
● WCDMA/HSPA+ (1, 2, 4, 5, 8)
● LTE(B1, B2, B3, B4, B5, B7, B8, B12,
B13, B14, B18, B19, B20, B25, B26,
B28, B29, B32, B38, B39, B40, B41,
B42, B43, B48, B66, B71)
● HSPA+ (1,2,4,5,6,8,9,19)
Wireless standards
● NR FR1 (Sub6) FDD/TDD
● LTE FDD/TDD
● WCDMA/HSPA+
● GPS/GLONASS/Beidou/Galileo
● LTE FDD/TDD
● WCDMA/HSPA+
● GPS/GLONASS/Beidou/Galileo/
QZSS
Encryption Supported Not supported
Global Navigation Satellite System
(GNSS)
Supports GPS, and GLONASS Location
sensor
Supports GPS, and GLONASS Location
sensor
NOTE: For instructions on how to find your computer's International Mobile Station Equipment Identity (IMEI) number,
search in the Knowledge Base Resource at Dell Support Site.
Optional GPS module
The following table lists the u-blox NEO-M9N module that is supported on your Dell Pro Rugged 14.
Table 12.
u-blox NEO-M9N module specifications
u-blox NEO-M9N module
Interface USB (default) and UART
Performance
Receiver type 92-channel u-blox M9 engine
GPS L1 C/A, QZSS L1 C/A/S, GLONASS L10F, BeiDou B1l,
Galileo E1 B/C
SBAS L1 C/A: WAAS, EGNOS, MSAS, GAGAN
Navigation update rate (maximum) 25 Hz (four concurrent GNSS modes)
Position accuracy 2.0 m CEP (four concurrent GNSS modes)
Supported protocol
● UBX
● NMEA 4.10 (default), 4.0, 2.3, and 2.1
● RTCM 3.3
Security features
● Anti-jamming
● Anti-spoofing
● Configuration lockdown
● Message integrity
● Secure boot
● JTAG debug port (locked by default)
Absolute maximum ratings
Power supply voltage
-0.5 V (minimum)
22 Specifications of Dell Pro Rugged 13 RA13250
